CB-7080 & CB-7080D Counter/Timer User's Guide

$AA1H(data)

Description : Sets the high trigger level of non-isolated inputs. Refer to
setting" for more information.
Syntax : $AA1H(data)[chk](cr)
$
AA
(data)
[chk]
(cr)
Response :
Valid response
Invalid response
no response
!
?
AA
[chk]
if checksum is disabled no [chk]
(cr)
Examples :
High trigger level=2.4 volts
command:
response:
High trigger level=3.0 volts
command:
response:
Note:
The default value for the high trigger level is 2.4V
A delimiter character
2-character HEX module address, from 00 to FF
2-character decimal value for high trigger level. The unit is 0.1 volt, and the range
can be from 0.0 to 5.0V.
2-character checksum. If checksum is disabled, no [chk].
0x0D
!AA[chk](cr)
?AA[chk](cr)
Syntax error, communication error or address error
A delimiter character indicating a valid response
A delimiter character indicating an invalid response
2-character HEX module address
2-character checksum,
0x0D
$011H24(cr)
!01(cr)
$021H30(cr)
!02(cr)
"Programmable threshold voltage
2-14
$AA1H(data)
