Connectors
Table 21.
Pin number
1, 3, 4, 6, 7, 9,
10, 12
2, 5, 8, 11, 17
13
14
3.3

RF EEPROM daughterboard connector CN3

Figure 10. RF EEPROM daughterboard connector CN3 (front view)

Table 22.
Pin number
1
2
3.4

CAN D-type 9-pin male connector CN5

Figure 11. CAN D-type 9-pin male connector CN5

Table 23.
Pin number
1, 4, 8, 9
2
32/66
HDMI source connector CN2
Description
TMDS differential signal pair
connected to CN1
GND
CEC (PB8 through NMOS)
NC
RF EEPROM daughterboard connector CN3
Description
SDA (PA10)
SCL (PA9)
CAN D-type 9-pin male connector CN5
Description
NC
CANL
Doc ID 023566 Rev 1
Pin number
15
16
18
19
Pin number
3
4
1 2 3 4 5
6 7 8 9
Front view
Pin number
7
3, 5, 6
UM1564
Description
I2C2_SCL (PA9)
I2C2_SDA (PA10)
HDMI_5V_Source from power
switch U1
HPD (PD7)
Description
+5 V
GND
Description
CANH
GND
MS19140V2
