UM1564
3.13

JTAG/SWD debugging connector CN17

Figure 19. JTAG/SWD debugging connector CN17 (top view)

Table 33.
Pin number
1
3
5
7
9
11
13
15
17
19
3.14

Power connector CN18

The STM32373C-EVAL evaluation board can be powered by a DC 5V power supply via the
external power supply jack connector (CN18) shown in
must be positive.

Figure 20. Power supply connector CN18 (front view)

19 17 15
20 18 16
JTAG/SWD debugging connector CN17
Description
VDD power
PB4
PA15
PA13
PA14
RTCK
PB3
RESET#
DBGRQ
DBGACK
Doc ID 023566 Rev 1
13 11 11 9 9 7 5 3
14 12 10 8 6 4
Pin number
2
4
6
8
10
12
14
16
18
20
Figure
Connectors
1
2
MS30946V1
Description
VDD power
GND
GND
GND
GND
GND
GND
GND
GND
GND
20. The central pin of CN18
41/66
