CAN

The STM32373C-EVAL evaluation board supports one channel of CAN2.0A/B complaint
CAN bus communication based on a 3.3-V CAN transceiver. High-speed mode, Standby
mode, and Slope control mode are available and can be selected by setting JP3.
Table 14.
Jumper
JP3
JP2
CAN operates correctly when VDD > 3 V.
2.15

HDMI CEC

Two HDMI connectors, CN1 and CN2, are available on the STM32373C-EVAL evaluation
board.
●
Connector CN1 is a HDMI sink connector with:
–
–
–
●
Connector CN2 is an HDMI source connector with:
–
–
–
–
The signals TDMS D+[0:2], TDMS_CLK+, TDMS D-[0:2], and TDMS_CLK- are connected
together on these two HDMI connectors.
CEC injector mode can be enabled (for debugging purposes only) as follows:
●
Remove resistors R120, R172, R173, R174, R175, R213, and R221.
●
Close solder bridges SB1, SB2, SB3, and SB4.
CAN-related jumpers
The CAN transceiver operates in Standby mode when JP3 is set
as shown to the right:
The CAN transceiver operates in High-speed mode when JP3 is
set as shown to the right:
This is the default setting.
The CAN transceiver operates in Slope control mode when JP3 is open.
When JP2 is fitted, the CAN terminal resistor is enabled.
Default setting: not fitted.
DDC connected to I2C1 of the STM32F373VCT6
HPD controlled by IO PE0 through transistor T1
CEC connected to PB8 through transistor T2
DDC connected to I2C2 (and shared with the temperature sensor, RF EEPROM,
and audio codec) of the STM32F373VCT6 by setting jumper JP4 and JP5 as
shown in Table 10: Audio-related
HPD controlled by IO PD7
CEC connected to PB8 through transistor T2
HDMI 5-V powered by power switch U1
