Connectors
3.11

ETM Trace debugging connector CN15

Figure 17. ETM Trace debugging connector CN15 (top view)

Table 31.
Pin number
1
3
5
7
9
11
13
15
17
19
3.12

User USB type B connector CN16

Figure 18. User USB type B connector CN16 (front view)

Table 32.
Pin number
1
2
3
40/66
19 17 15
20 18 16
ETM Trace debugging connector CN15
Description
VDD power
GND
GND
KEY
GND
GND
GND
GND
GND
GND
User USB type B connector CN16
Description
VBUS (power)
DM
DP
Doc ID 023566 Rev 1
13 11 11 9 9 7 5 3
14 12 10 8 6 4
Pin number
2
4
6
8
10
12
14
16
18
20
Pin number
4
5, 6
1
2
MS30946V1
Description
TMS/PA13
TCK/PA14
TDO/PB3
TDI/PA15
RESET#
TraceCLK/PE2
TraceD0/PE3 or SWO/PB3
TraceD1/PE4 or nTRST/PB4
TraceD2/PE5
TraceD3/PE6
Description
GND
Shield
UM1564
