Hardware layout and configuration
2.24

Display and input devices

The 240x320 TFT color LCD connected to port SPI3 of STM32F373VCT6 (shared with the
MicroSD card) and four general-purpose color LEDs (LD1, LD2, LD3, LD4) are available as
display devices. LED LD9 is connected with PA7 to show the status of comparator 2 when
debugging. The 4-direction joystick (U34) with selection wakeup button (B2) and key button
(B3) are available as input devices.
The LCD can be enabled by chip select signal PD2 and this signal should be set as open-
drain output pin in STM32F373VCT6. All joystick signals should be set as pull-down input
pin in STM32F373VCT6.
Table 19.
Pin on CN20
30/66
LCD modules
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Doc ID 023566 Rev 1
TFT LCD CN20
Description
CS
SCL
SDI
RS
WR
RD
SDO
RESET
VDD
VCI
GND
GND
BL_VDD
BL_Control
BL_GND
BL_GND
UM1564
Pin connection
PD2
PC10
PC12
-
-
-
PC11
RESET#
3.3V
3.3V
GND
GND
3.3V
3.3V
GND
GND
