STM32373C-EVAL pinout
Table 35.
Pin
no.
61
PD14
62
PD15
63
PC6
64
PC7
65
PC8
66
PC9
67
PA8
68
PA9
69
PA10
70
PA11
71
PA12
72
PA13
73
PF6
74
VSS_3
75
VDD_3
76
PA14
77
PA15
78
PC10
79
PC11
80
PC12
81
PD0
82
PD1
83
PD2
84
PD3
85
PD4
86
PD5
87
PD6
88
PD7
89
PB3
90
PB4
91
PB5
92
PB6
93
PB7
94
BOOT0
62/66
STM32373C-EVAL pinout (continued)
Pin name
Doc ID 023566 Rev 1
Description
SLIDER_3
SLIDER_CT
I2S_WS
I2S_CK
I2S_MCK
I2S_DIN
I2C2_SMB
I2C2_SCL
I2C2_SDA
USB_DM
USB_DP
SWDAT/JTMS
-
SWCLK/JTCK
JTDI
SPI3_SCK
SPI3_MISO
SPI3_MOSI
CAN_RX
CAN_TX
LCD_CS
USART2_CTS
USART2_RTS
USART2_TX/ IRDA
USART2_RX/ IRDA
HDMI_HPD_SOURCE
JTDO/TRACESWO
JNTRST
IR_IN
I2C1_SCL
I2C1_SDA
BOOT0
