Table 35.
Pin
no.
29 PA4
30 PA5
31 PA6
32 PA7
33 PC4
34 PC5
35 PB0
36 PB1
37 PB2
38 PE7
39 PE8
40 PE9
41 PE10
42 PE11
43 PE12
44 PE13
45 PE14
46 PE15
47 PB10
48 SD_VREF-
49 SDADC1_SDADC2_SDADC3_VSS
50 SDADC1_SDADC2_VDD
51 SDADC3_VDD
52 SD_VREF+
53 PB14
54 PB15
55 PD8
56 PD9
57 PD10
58 PD11
59 PD12
60 PD13
STM32373C-EVAL pinout (continued)
Pin name
Doc ID 023566 Rev 1
STM32373C-EVAL pinout
Description
ADC_DAC_SAR1
ADC_DAC_SAR2
DAC2_OUT1_AUDIO / ECG_DAC
COMP2_OUT_LED
-
USB_DISCONNECT
MIC_IN
ADC_POT_IN
1.8V POR_RFU
RTD_IN
PRESSURE_P
PRESSURE_N
-
ADC_SD
ECG
-
PRESSURE_TEMPERATURE
-
-
-
-
-
-
-
AUDIO_RST
SLIDER_1
SLIDER_2
