Appendix Astm32373C-Eval Pinout; Table 35. Stm32373C-Eval Pinout - ST STM32373C-EVAL User Manual

STM32373C-EVAL pinout
Appendix A
Table 35.
Pin
no.
1 PE2
2 PE3
3 PE4
4 PE5
5 PE6-WKUP3
6 VBAT
7 PC13-TAMPER-WKUP2
8 PC14-OSC32_IN
9 PC15-OSC32_OUT
10 PF9
11 PF10
12 PF0 - OSC_IN
13 PF1 - OSC_OUT
14 NRST
15 PC0
16 PC1
17 PC2
18 PC3
19 PF2
20 VSSA / SAR_VSS / SAR_VREF-
21 VDDA / SAR_VDD
22 SAR_VREF+
23 PA0 - WKUP1
24 PA1
25 PA2
26 PA3
27 PF4
28 VDD_2
60/66
STM32373C-EVAL pinout
STM32373C-EVAL pinout
Pin name
Doc ID 023566 Rev 1
Description
TRACECLK / SPI3_CS_uSDcard
TRACED0 / uSDcard_Detect
TRACED1 /SHIELD
TRACED2 / SHIELD_CT
TRACED3 / WKUP_JOYSTICK_SEL
VBAT
-
OSC32_IN
OSC32_OUT
JOYSTICK_RIGHT
JOYSTICK_UP
OSC_IN
OSC_OUT
NRST
LED1
LED2
LED3
LED4
JOYSTICK_DOWN
WKUP_BUTTON / IDD
LDR_OUT
KEY_BUTTON
COM_IN+
JOYSTICK_LEFT
UM1564
