UM1564
A 100 Ω 0.1% resistor, R121, is used to calibrate PT100 by setting JP18.
Note:
Table 17.
Jumper
JP18
Note:
The temperature result measured from PT100 is slightly higher than ambient temperature
due to board heat.
PT100-related jumper
The 100-ohm 0.1% resistor is connected for calibration when
JP18 is set as shown to the right:
PT100 resistor is connected to measure temperature when JP18
is set as shown to the right:
This is the default setting.
Doc ID 023566 Rev 1
Hardware layout and configuration
Description and jumper setting
1
2
3
1
2
3
25/66
