How to Programme
6.7 Parameters: 8-** Communications and
Options
6.7.1 8-0* General Settings
8-01 Control Site
Option:
[0] Digital and ctrl.
*
word
[1] Digital only
[2] Control word only
The setting in this parameter overrides the settings in
8-50 Coasting Select to 8-56 Preset Reference Select.
6 6
8-02 Control Word Source
Option:
[0]
[1]
*
[2]
8-03 Control Word Timeout Time
Range:
1 s [ 0.1 -
*
18000 s]
This parameter specifies which action should be
performed, if a timeout of the control word occurs.
8-04 Control Word Timeout Function
Option:
[0]
*
[2]
[5]
8-06 Reset Control Word Timeout
Option:
[0]
*
[1]
54
Function:
Control by using both digital input
and control word.
Control by using digital inputs only.
Control by using control word only.
Function:
None
FC RS485
FC USB
Function:
Enter the maximum time expected to pass
between the reception of two consecutive
telegrams. If this time is exceeded, it indicates
that the telegram communication has stopped.
The function selected in 8-04 Control Word
Timeout Functionis then carried out. A valid
control word triggers the time-out counter.
Function:
Off
Stop
Stop and trip
Function:
Do not reset
Do reset
Danfoss A/S © Rev. 05/2014 All rights reserved.
Operating Instructions
6.7.2 8-1* Control Word Settings
Parameters for configuring the option control word profile.
This parameter selects the interpretation of the control
word and status word. Valid selections are determined by
installed option.
8-10 Control Word Settings
Option:
[0]
*
Bit
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Table 6.4 Bus Control Word
Function:
FC AFE profile
AFE Profile
Bit = 0 Bit = 1
- -
- -
- -
- -
- -
- -
Stop Start
No Function Reset
- -
- -
Data not valid Data valid
- -
- -
- -
- -
- -
MG33X402
