How to Programme
Bit
Bit = 0
0 Control not ready
1 Unit not ready
2 Soft charge not
ready
3 No trip
4 -
5 -
6 No TripLock
7 No warning
8 DC-link not on
reference
9 Local control
10 Not ramping
11 Not running
12 -
13 No DC voltage
warning
14 No current limit
15 No Thermal
warning
Table 6.5 Bus Status Word
8-13 Configurable Status Word STW
Option: Function:
Bit 12 to 15 of the STW is config-
urable for various status signals.
[0] No function
[1] Profile default
*
[2] Alarm 68 only
[3] Trip except Alarm 68
[16] T37 DI status
6.7.3 8-3* FC Port Settings
8-30 Protocol
Option: Function:
[0] FC Communication according to the FC Protocol as
*
described in the VLT AutomationDrive Design Guide,
RS-485 Installation and Set-up.
[1] FC MC Select the protocol for the FC (standard) port.
8-31 Address
Range: Function:
Size related [ 1 - 255 ] Enter the address for the FC (standard)
*
port.
Valid range: 1-126.
MG33X402
Operating Instructions
AFE Profile
Bit = 1
Control ready
Unit ready
Soft charge ready
Trip
-
-
TripLock
Warning
DC-link on reference
Remote control
Ramping
Running
-
DC voltage warning
Current limit
Thermal warning
Danfoss A/S © Rev. 05/2014 All rights reserved.
8-32 FC Port Baud Rate
Option: Function:
[0] 2400 Baud Baud rate selection for the FC (standard) port.
[1] 4800 Baud
[2] 9600 Baud
[3] 19200 Baud
[4] 38400 Baud
[5] 57600 Baud
[6] 76800 Baud
[7] 115200 Baud
8-35 Minimum Response Delay
Range: Function:
10 ms [ 1 - 10000 Specify the minimum delay time
*
ms] between receiving a request and
transmitting a response. This is used for
overcoming modem turnaround delays.
8-36 Max Response Delay
Range: Function:
Size [ 11 - Specify the maximum permissible
related 10001 ms] delay time between transmitting a
*
request and receiving a response. If a
response from the frequency converter
is exceeding the time setting, then it is
discarded.
8-37 Max Inter-Char Delay
Range: Function:
Size [ 0.00 - Specify the maximum permissible time
related 35.00 ms] interval between receipt of 2 bytes.
*
This parameter activates time-out if
transmission is interrupted.
This parameter is active only when
8-30 Protocol is set to [1] FC MC
protocol.
Enables use of freely configurable telegrams or standard
telegrams for the FC port.
8-40 Telegram Selection
Option:
[1] Standard Telegram 1
*
[101] PPO 1
[102] PPO 2
[103] PPO 3
[104] PPO 4
[105] PPO 5
[106] PPO 6
[107] PPO 7
[108] PPO 8
[200] Custom telegram 1
6 6
Function:
