How to Programme
15-21 Historic Log: Value
Array [50]
Range:
6
6
15-22 Historic Log: Time
Array [50]
0
[0 - 2147483647
*
s]
6.9.3 15-3* Alarm Log
Parameters in this group are array parameters, where up to
10 fault logs can be viewed. [0] is the most recent logged
data, and [9] the oldest. Error codes, values, and time
stamp can be viewed for all logged data.
15-30 Fault Log: Error Code
Array [10]
Range:
0
[0 - 255 ] View the error code and look up its meaning in .
*
15-31 Alarm Log: Value
Array [10]
Range:
0
[-32767 - 32767 ] View an extra description of the error.
*
60
Operating Instructions
Function:
Digital output
Decimal value. See
(not
parameter 16-66 Digital
monitored in
Output [bin] for
this SW
description after
release)
converting to binary
value.
Warning word Decimal value. See
16-92 Warning Word for
description.
Alarm word
Decimal value. See
16-90 Alarm Word for
description.
Status word
Decimal value. See
16-03 Status Word for
description after
converting to binary
value.
Control word
Decimal value. See
16-00 Control Word for
description.
Extended
Decimal value. See
status word
parameter 16-94 Ext. Status
Word for description.
View the time at which the logged
event occurred. Time is measured in ms
since frequency converter start.
Function:
Function:
This parameter is mostly used in
combination with alarm 38 internal fault.
Danfoss A/S © Rev. 05/2014 All rights reserved.
15-32 Fault Log: Time
Array [10]
0
[0 - 2147483647 s] View the time when the logged event
*
occurred. Time is measured in seconds
from frequency converter start-up.
6.9.4 15-4* Drive Identification
Parameters containing read only information about the
hardware and software configuration of the AFE.
15-40 AFE Type
Option: Function:
View the AFEtype. The read-out is identical to the FC
300 Series power field of the type code definition,
characters 1-6.
15-41 Power Section
Option: Function:
View the AFE type. The read-out is identical to the FC
300 Series power field of the type code definition,
characters 7-10.
15-42 Voltage
Option: Function:
View the AFE type. The read-out is identical to the FC
300 Series power field of the type code definition,
characters 11-12.
15-43 Software Version
Range:
Function:
0
[0 - 5 ] View the combined SW version (or 'package
*
version') consisting of power SW and control SW.
15-44 Ordered Typecode String
Option: Function:
View the type code string used for re-ordering the AFE
in its original configuration.
15-45 Actual Typecode String
Range:
Function:
0
[0 - 40 ]
View the actual type code string.
*
15-46 AFE Ordering No
Option: Function:
View the 8-digit ordering number used for re-ordering
the AFE in its original configuration.
15-47 Power Card Ordering No
Range:
Function:
0
[0 - 8 ]
View the power card ordering number.
*
MG33X402
