Mechanical Dimensions - Danfoss VLT Active Front End AFE 302 Operating Instructions Manual

How to Install

4.2.5 Mechanical Dimensions

597.0
ADD 3MM
BETWEEN
TWO CABINET
TO ACCOUNT
FOR GASKET
2003.4
ALL CABINET
1296.0
ALL CABINET
SEE VIEW A
540.5 540.5
493.5
338.4
294.0
2X 219.4
2X 81.4
73.0
65.5 65.5
0.0 0.0
CABINET
CABINET
BACK
BACK
WALL
WALL
600MM CABINET
BOTTOM VIEW
Illustration 4.6 Dimensions
1597.0
4X 540.5
2X 493.5
2X 294.0
4X 219.4
4X 81.4
4X 65.6
0.0
CABINET
BACK
WALL
Illustration 4.7 Dimensions 1600 mm Cabinet
MG33X402
Operating Instructions
797.0
ADD 3MM
BETWEEN
TWO CABINET
TO ACCOUNT
FOR GASKET
540.5
493.5
294.0
3X 222.8
3X 81.4
65.5
0.0
CABINET
BACK
WALL
800MM CABINET 1200MM CABINET
BOTTOM VIEW BOTTOM VIEW
Danfoss A/S © Rev. 05/2014 All rights reserved.
1197.0
CABINET
AIR IN
2078.4
ALL CABINET
WITH LIFT
BRACKET
CABINET
AIR OUT
BACK CHANNEL
AIR IN
605.6
635.2
BACK CHANNEL
AIR OUT
X
VIEW A
27
4 4
