How to Install
limit the energy into the frequency converter to an equal
or lower level than the compliant circuit breakers.
If fuses/circuit breakers according to recommendations are
selected, possible damage on the frequency converter is
mainly limited to damage inside the unit.
4.3.8 High Power Fuses
4 4
525-690 V, frame sizes D, E and F
The fuses below are suitable for use on a circuit capable of
delivering the Short Circuit Current Rating (SCCR) of
100,000 Amps (symmetrical).
Bussmann
Size/Type
P630- 170M7081
P900
P1M0 170M7082
P1M2- 170M7083
P1M4
P1M6 170M7084
Table 4.5 Frame Size F, Line Fuses, 525-690 V
Bussmann
Size/Type
P630- 170M8611
P1M6
Table 4.6 Frame Size F, Inverter Module DC Link Fuses, 525-690 V
*170M fuses from Bussmann use the -/80 visual indicator, -TN/80
Type T, -/110 or TN/110 Type T indicator fuses of the same size and
amperage may be substituted for the external use.
Supplementary fuses
Frame size
D, E and F
Table 4.7 SMPS Fuse
Size/Type
P37K-P400,
525-690 V
P500-P1M6,
525-690 V
Table 4.8 Fan Fuses
Bussmann PN
FWC-20A-10F
Table 4.9 Fan Voltage/Softcharge Fuse
34
Rating
PN*
1600 A, 700 V 20 695 32.1600
2000 A, 700 V 20 695 32.2000
2500 A, 700 V 20 695 32.2500
3000 A,700 V
Rating
PN*
1100 A, 20 781 32. 1000
1000 V
Bussmann PN*
KTK-4
Bussmann PN* LittelFuse
KTK-4
KLK-15
Rating
20 A, 600 V
Danfoss A/S © Rev. 05/2014 All rights reserved.
Operating Instructions
Siba
Siba
Rating
4 A, 600 V
Rating
4 A, 600 V
15 A, 600 V
MG33X402
