How to Programme

6.3 Parameters: 4-** Limits/Warnings

6.3.1 4-1* Limits
Use these parameters to adjust warning limits for power.
Warnings are shown on the LCP, can be programmed as
outputs, and can be read out via the serial bus in the
Extended Status Word.
4-18 Current Limit
Range:
Size related
*
6 6 6.3.2 4-5* Adjustable Warnings
4-52 Warning Regen Limit
Range:
Size [0-2*Nominal
related NO Power kW]
*
4-53 Warning Power Limit
Range:
Size [0-2*Nominal
related NO Power kW]
*
6.3.3 4-9* Output Limits
4-90 Output Frequency Deviation Function
Option:
[0] Trip
*
[1] Warning Generate a warning when a fault condition is
[2] Disabled Take no action on fault condition.
Select which reaction the AFE should take in case the
frequency deviation set in parameter 4-91 Output Frequency
Deviation Limit.
48
Function:
[ 1.0 - 1000.0 %] This is a true current limit
function.
Function:
Enter the regen power limit. When
the regenerative power exceeds
this limit the display reads Regen
Limit. The signal outputs can be
programmed to produce a status
signal on terminals 27 or 29 and
on relay outputs 01 or 02.
Function:
Enter the active power limit. When
the active power exceeds this limit
the display reads Power Limit. The
signal outputs can be programmed
to produce a status signal on
terminals 27 or 29 and on relay
outputs 01 or 02.
Function:
Select the time-out function. The time-out
function activates when the output frequency
exceeds the deviation limit set in parameter 4-91
Output Frequency Deviation Limit for the time set
in parameter 4-92 Output Frequency Deviation
Timeout
Generate an alarm trip when a fault condition is
encountered.
encountered.
Danfoss A/S © Rev. 05/2014 All rights reserved.
Operating Instructions
4-91 Output Frequency Deviation Limit
Range:
20%
*
4-92 Output Frequency Deviation Timeout
Range:
0.001 s
*
4-93 Output Voltage Deviation Function
Option:
[0] Trip
*
[1] Warning Generate a warning when a fault condition is
[2] Disabled Take no action on fault condition.
Select which reaction the AFE should take in case the
voltage deviation set in parameter 4-94 Output Voltage
Deviation Limit is exeeded.
4-94 Output Voltage Deviation Limit
Range:
20%
*
4-95 Output Voltage Deviation Timeout
Range:
0.001 s
*
Function:
[1 - 50%] Selects the max deviation in procentage from
the nominiel mains frequency set in parameter
40-01 Mains Frequency
Function:
[0.000 - 60.000 Selects the max time where the
s] frequency deviation set in parameter
4-91 Output Frequency Deviation Limit
can be exceeded.
Function:
Select the time-out function. The time-out
function activates when the output vontage
exceeds the deviation limit set in parameter 4-91
Output Frequency Deviation Limit for the time set
in parameter 4-92 Output Frequency Deviation
Timeout.
Generate an alarm trip when a fault condition is
encountered.
encountered.
Function:
[1 - 50%] Selects the max deviation in procentage from
the nominiel mains voltage set in parameter
40-00 Mains Voltage.
Function:
[0.000 - 60.000 Selects the max time where the
s] voltage deviation set in parameter
4-94 Output Voltage Deviation Limit
can be exceeded.
