How to Programme
6.2.3 0-2* LCP Display
Parameters used to select what kind of information (e.g.
power, current, frequency) should be displayed in the
STATUS window.
0-20 Display Line 1.1 Small
Option: Function:
Select a variable for display in line 1,
left position.
[0] None No display value selected.
[1501] Running Hours
[1502] kWh Counter
[1600] Control Word Present control word
[1603] Status Word Present status word.
[1630] DC Link Voltage Intermediate circuit voltage in the AFE.
[1634] Heatsink Temp. Present heat sink temperature of the
AFE. The cut-out limit is 95 ±5°C;
cutting back in occurs at 70 ±5°C.
[1635] Inverter Thermal Percentage load of the inverters.
[1636] Inv. Nom. Nominal current of the AFE.
Current
[1637] Inv. Max. Current Maximum current of the AFE.
[1639] Control Card Temperature of the control card.
Temp.
[1641] Current Value of measured current
[1642] Voltage Shows the actual mains voltage, when
the AFE is running.
[1643] Frequency Returns the actual mains frequency,
when the AFE is running.
[1644] Power [kW] Returns the calculated mains power in
kW
[1645] Power [hp] Returns the calculated mains power in
HP.
[1660] Digital Input Signal states form the 6 digital
terminals (18, 19, 27, 29, 32 and 33).
Input 18 corresponds to the bit at the
far left. Signal low = 0; Signal high =
1.
[1665] Analog Output Shows the value at output 42 in mA.
42 [mA]
[1666] Digital Output Binary value of all digital outputs.
[bin]
[1671] Relay Output [bin Shows all the relay settings.
[1680] Fieldbus CTW 1 Control word (CTW) received from the
Bus Master.
[1682] Fieldbus REF 1 Main reference value sent with control
word from the Bus Master.
[1684] Comm. Option Extended fieldbus communication
STW option status word.
[1685] FC Port CTW 1 Control word (CTW) received from the
Bus Master.
[1686] FC Port REF 1 Status word (STW) sent to the Bus
Master.
[1690] Alarm Word One or more alarms in a Hex code.
[1691] Alarm Word 2 One or more alarms in a Hex code.
MG33X402
Operating Instructions
0-20 Display Line 1.1 Small
Option:
[1692] Warning Word
[1693] Warning Word 2
[1694] Ext. Status Word
0-21 Display Line 1.2 Small
Option:
[1641]
*
0-22 Display Line 1.3 Small
Option:
[1644]
*
0-23 Display Line 2 Large
Option:
[1643]
*
0-24 Display Line 3 Large
Option:
[1630]
*
0-25 My Personal Menu
Range:
Size
related
*
Danfoss A/S © Rev. 05/2014 All rights reserved.
Function:
One or more warnings in a Hex code.
One or more warnings in a Hex code.
One or more status conditions in a
Hex code.
Function:
Mains Current Select a variable for display in line 1,
[A] middle position. The options are the
same as listed for parameter group 0-2*
LCP Display.
Function:
Power [kW] Select a variable for display in line 1, right
position. The options are the same as listed
for parameter group 0-2* LCP Display.
Function:
Frequency [Hz] Select a variable for display in line 2.
The options are the same as those
listed for parameter group 0-2* LCP
Display.
Function:
Select a variable for display in line 2.
Counter [kWh]
The options are the same as those listed
for 0-20 Display Line 1.1 Small.
Function:
[0 - Define up to 50 parameters to appear in the
9999] Q1 Personal Menu, accessible via the [Quick
Menu] key on the LCP. The parameters are
displayed in the Q1 Personal Menu in the
order they are programmed into this array
parameter. Delete parameters by setting the
value to '0000'.
For example, this can be used to provide
quick, simple access to just one or up to 50
parameters which require changing on a
regular basis (e.g. for plant maintenance
reasons) or by an OEM to enable simple
commissioning of their equipment.
