How to Programme
6.11 Parameters: 40-** Mains / Filter
6.11.1 40-0* Mains Data
40-00 Mains Voltage
Range:
630 V
[[525-690 V]]
*
40-01 Mains Frequency
Option:
[0]
50 Hz
*
[1]
60 Hz
40-02 Mains Inductance
6
6
Range:
0.039 mH
[0.000 - 65.000
*
mH]
40-03 Mains Resistance
Range:
0.50 mOhm
*
6.11.2 40-1* LCL Filter
40-10 Mains Side Inductance (Lm)
Range:
0.029 mH
[0.000 - 65.000
*
mH]
40-11 Mains Side Resistance (Rm)
Range:
0.19 mOhm
*
40-12 Converter Side Inductance (Lc)
Range:
0.100 mH
[0.000 - 65.000
*
mH]
40-13 Converter Side Resistance (Rc)
Range:
0.48 mOhm
*
40-14 Filter Capacity (Cf)
Range:
400 uF
[0 - 65000 uF] Set the capacitance of the LCL filter.
*
64
Function:
Set the mains voltage line to line.
Function:
Set the mains nominal frequency.
Function:
Set the Inductance of the mains.
This could be the transformer.
Function:
[0.00 - 650.00
Set the value of the mains
mOhm]
resistance. This could be the
transformer.
Function:
Set the main side inductance
of the LCL filter.
Function:
[0.00 - 650.00
Set the main side resistance
mOhm]
of the LCL filter.
Function:
Set the converter side
inductance of the LCL filter.
Function:
[0.00 - 650.00
Set the converter side
mOhm]
resistance of the LCL filter.
Function:
The value is for the delta configuration.
Danfoss A/S © Rev. 05/2014 All rights reserved.
Operating Instructions
MG33X402
