Hydran* M2-X Instruction Manual

3.6 Service Menu

3.6.1

Sensors Parameters

3.6.1.1 Gas Sensor Param
The Gas Sensor Param function gives access to the parameters of the gas
sensor. Each gas sensor has its own set of parameter values; the values are
indicated on the Test Certificate and Data Sheet (for an example, see Figure 3-12)
supplied with the Hydran M2-X. These options do not allow you to modify the
displayed values. To change the values, use Install New Sensor (see Section 3.6.2).
The gas sensor parameters are:
• Gas Serial No.:
connector). The same serial number is used for the gas sensor and humidity
sensor.
• B, M, N, S and A1 to A6: The ten parameters of the gas sensor in a normalized
format (integer numbers).
– The Hydran M2-X computes the gas level in ppm by performing two readings:
the sensor temperature (provided by the thermistor incorporated in the
sensor) and the gas sensor output (gas level). The calculation also requires
these ten parameters (from B to A6).
– These ten parameters characterize the behavior of the gas sensor by
modeling its response according to the temperature.
– The values of these ten parameters are stored in the Hydran M2-X's
nonvolatile memory (see Section 2.3.4.3).
• Gas Param CkSum: Checksum of the above values. This value is added to the list
to avoid erroneous values from being entered.
Note: The Hydran M2-X uses the proven technology of the Hydran M2-X sensor. For a
complete description, see Section 2.4.
3.6.1.2 H O Sensor Param
2
The H2O Sensor Param function gives access to the parameters of the moisture
sensor. Each moisture sensor has its own set of parameter values; the values are
indicated on the Test Certificate and Data Sheet (for an example, see Figure 3-12)
supplied with the Hydran M2-X. These options do not allow you to modify the
displayed values. To change the values, use Install New Sensor (see Section 3.6.2).
• H2O SerialNo.:
connector). The same serial number is used for the gas sensor and humidity
sensor.
• H
O Param C1 to C10: The ten parameters of the moisture sensor in a
2
normalized format (integer numbers).
MA-029 Rev. 1.0, 30-Jul-18
Serial number of the sensor (engraved under the sensor
Serial number of the sensor (engraved under the sensor
Page 61
