Hydran* M2-X Instruction Manual
Note: Appendix I presents the list of all alarm messages that can appear in the
Perception software.
3.3.2.3 Temperature Alarms Setup
• Hydran Sensor Temp Alarm: Gives access to the sensor temperature Low-Low,
Low, High and High-High alarm parameters:
– Alarm Low-Low SP: Set point of the sensor temperature Low-Low alarm
condition.
– Alarm Low SP: Set point of the sensor temperature Low alarm condition.
– Alarm Hi SP: Set point of the sensor temperature High alarm condition.
– Alarm Hi-Hi SP:
condition.
– Alarm Delay: Alarm delay, in minutes, for all above set points.
– Alr C. Open Relay: Relay activated when a sensor temperature Low-Low
alarm condition is detected.
– Alarm Low Relay: Relay activated when a sensor temperature Low alarm
condition is detected.
– Alarm Hi Relay: Relay activated when a sensor temperature High alarm
condition is detected.
– Alr C. Short Relay: Relay activated when a sensor temperature High-High
alarm condition is detected.
• Base Plate Temp Alarm: Gives access to the base plate temperature Low-Low,
Low, High and High-High alarm parameters:
– Alarm Low-Low SP: Set point of the base plate temperature Low-Low alarm
condition.
– Alarm Low SP: Set point of the base plate temperature Low alarm condition.
– Alarm Hi SP: Set point of the base plate temperature High alarm condition.
– Alarm Hi-Hi SP: Set point of the base plate temperature High-High alarm
condition.
– Alarm Delay: Alarm delay, in minutes, for all above set points.
– Alr C. Open Relay: Relay activated when a base plate temperature Low-Low
alarm condition is detected.
– Alarm Low Relay: Relay activated when a base plate temperature Low alarm
condition is detected.
– Alarm Hi Relay: Relay activated when a base plate temperature High alarm
condition is detected.
– Alr C. Short Relay: Relay activated when a base plate temperature High-High
alarm condition is detected.
Note: Appendix I presents the list of all alarm messages that can appear in the
Perception software.
3.3.2.4 Battery Alarm Setup
The Battery Alarm Setup functions give access to the battery's alarm
parameters:
MA-029 Rev. 1.0, 30-Jul-18
Set point of the sensor temperature High-High alarm
