Hydran* M2-X Instruction Manual
Description
Low-Low sensor temperature
Low sensor temperature
High sensor temperature
High-High sensor
temperature
a.
b.
c.
d.
6.3.2.2 Base Plate Temperature Alarm Conditions
The parameters pertaining to these alarm conditions are presented in Table 6-6
6-6 below. The heater plate temperature is measured using two thermistors in the
heater plate.
Description
Low-Low base plate
temperature
Low base plate temperature
High base plate temperature
High-High base plate
temperature
a.
b.
c.
d.
6.3.2.3 Battery Voltage Alarm Conditions
The parameters pertaining to the alarm conditions are presented in Table 6-7
below.
MA-029 Rev. 1.0, 30-Jul-18
Priority Alarm Set Point
a
High
b
b
Table 6-5: Hydran Sensor Temperature Alarm Conditions
All conditions likely indicate a faulty heating system.
The High and High-High alarms could be caused by a very high oil temperature.
Found in Alarms > Alarms Setup > Temp. Alarm Setup > Sensor Temp. Alarm
Found in Alarms > Alarms Setup > Sys. Fault Trigger
Priority Alarm Set Point
a
High
b
b
Table 6-6: Base Plate Temperature Alarm Conditions
All conditions likely indicate a faulty heating system.
The High and High-High alarms could be caused by a very high oil temperature.
Found in Alarms > Alarms Setup > Temp. Alarm Setup > Heater Plate Temp. Alarm
Found in Alarms > Alarms Setup > Sys. Fault Trigger
c Fault Trigger
Alarm Lo-Lo SP S. Temp L-Low Alr
Alarm Low SP S. Temp Low Alarm
Alarm Hi SP S. Temp Hi Alarm
Alarm Hi-Hi SP S. Temp Hi-Hi Alarm
c Fault Trigger
Alarm Lo-Lo SP B.P. Temp L-Low Alr
Alarm Low SP B.P. Temp Low Alarm
Alarm Hi SP B.P. Temp Hi Alarm
Alarm Hi-Hi SP B.P. Temp Hi-Hi
Alarm
d
d
