Appendix I. Alarm Messages

Table I-1 below presents the list of all alarm messages that can be displayed by
the Hydran M2-X and that can appear in the Perception software
Alarm Name
Hydran Level Hi Alarm
Hydran Level Hi-Hi Alarm
Hydran Hourly Trend Hi
Alarm
Hydran Daily Trend Hi
Alarm
Hydran Daily Trend Hi-Hi
Alarm
%RH Level Hi Alarm
%RH Level Hi-Hi Alarm
H2O PPM Level Hi Alarm
H2O PPM Level Hi-Hi
Alarm
%RH Hourly Average Hi
Alarm
%RH Hourly Average Hi-Hi
Alarm
H2O PPM Hourly Average
Hi Alarm
H2O PPM Hourly Average
Hi-Hi Alarm
Hydran Sensor Temp Low-
Low Alarm
Hydran Sensor Temp Low
Alarm
Hydran Sensor Temp Hi
Alarm
Hydran Sensor Temp Hi-Hi
Alarm
Base Plate Temperature
Page 190
Hydran* M2-X Instruction Manual
Alarm Message on the
Hydran M2-X Display
Gas Level Hi Alarm
Gas Level Hi-Hi Alr
Gas Hr.Tr. Hi Alarm
Gas Dy.Tr. Hi Alarm
Gas Dy.Tr. H-Hi Alr
%RH Hi Alarm
%RH Hi-Hi Alarm
H2O PPM Hi Alarm
H2O PPM Hi-Hi Alarm
%RH Avg.Hi Alarm
%RH Avg. Hi-Hi Alr
H2O PPM Avg. Hi Alr
H2O PPM Av. H-H Alr
S. Temp C.Open Alr
S. Temp Low Alarm
S. Temp Hi Alarm
S. Tmp C.Short Alr
B.P. Tmp C.Open Alr
Alarm Message in the
Perception Software
H2 PPM Level High
H2 PPM Level High-High
H2 PPM Hourly Trend
High-High
H2 PPM Daily Trend High
H2 PPM Daily Trend High-
High
H2O RH% Level High
H2O RH% Level High-High
H2O PPM Level High
H2O PPM Level High-High
HighH2O RH% Hourly
Average
H2O RH% Hourly Average
High-High
H2O PPM Hourly Average
High
H2O PPM Hourly Average
High-High
Sensor Temp Cable Open
Sensor Temp Low
Sensor Temp High
Sensor Temp Cable Short
Base Plate Temp Cable
MA-029 Rev. 1.0, 30-Jul-18
