Appendix B. Installation Checklist

WARNING
This Appendix lists every step of the installation procedure. The numbers on the
left indicate the Section numbers; those on the right indicate the page where this
Section is located.
4.3 Installation
4.3.1 Overview
1. Mount the sensor on a full-bore gate or ball valve
2. The valve's nominal diameter is 1.5 in or larger
3. Mount the Hydran M2-X horizontally
4.3.2 Verifying the Serial Numbers
1. Ensure the following serial numbers correspond to those indicated on the Test
Certificate and Data Sheet and the shipping box
•
Serial number of the sensor (located under the sensor's connector)
•
Serial number of the Hydran M2-X (located on the heater plate)
4.3.3 Preparing the Valve
1. Wipe the outside of the valve
2. Clean the valve's threads
3. Dispose of the collected oil according to the company regulations
4.3.4 Separating the Sensor from the Hydran M2-X
1. Remove the set screw that secures the Hydran M2-X and sensor
2. Remove the sensor clamp using the spanner wrench
3. Carefully pull the sensor a few centimeters from the enclosure
4. Disconnect the connector located at the back of the sensor
5. Inspect the membrane inside the sensor by looking at it
6. Store all parts in a box until ready for installation
Page 154
Read all warnings and recommendations in Chapter 1 before
proceeding with the installation.
Hydran* M2-X Instruction Manual
73
73
[ ]
[ ]
[ ]
77
[ ]
[ ]
79
[ ]
[ ]
[ ]
79
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
MA-029 Rev. 1.0, 30-Jul-18
