1. If necessary, remove the old power cables from the system. You must use the
power cables shipped with the slider shelf assembly.
2. Fully extend the slide tray from the cabinet (see Figure 4–8).
3. Connect one end of the power cable(s)
front of the system drawer.
NOTE: When routing a power cable, you must remove the cable clamp, insert
the cable in the clamp, and then reinstall it.
4. If the system has one power supply, route the power cable through the inside
cable clamps
on the left catch bracket.
5. If the system has a second power supply, route the power cable through the
outside cable clamps on the left catch bracket.
6. Route the power cable through the cable clamps
the slide tray. Then route it through the two cable clamps on the left rear edge
of the slide tray
.
7. Tie-wrap the cable to the cable management bracket
enough slack in the cable to prevent stress between the slide tray cable clamp
and the cable management bracket.
8. If the system has a third power supply, route the power cable through the cable
clamps on the right catch bracket. Then continue to route the cable as you did
the others, using the cable clamps underneath the right side of the slide tray.
to the AC input receptacle(s)
underneath the left side of
. Ensure that there is
Installing Components in Cabinet
on the
4-15
