System temperature is 24 degrees C
AlphaServer 4100 Console V2.0-1, 24-JUL-1996 10:47:18
P00>>>
NOTE: If the console and the system are configured in graphics mode (SRM console
environment variable (EV) is set to graphics), test information covered by callouts
through
will not display. If the SRM console EV os_type is set to NT, the
Windows NT AlphaBIOS console will be loaded by the SRM console, unless the
control panel Halt button is depressed. If this is the case, the SRM console ignores
the os_type setting and halts when the SRM power-up initialization and
configuration is completed.
SRM code runs on each CPU. The processor chips are tested and the path to the
system flash ROM is verified. Each CPU then loads XSROM from the system flash
ROM.
XSROM prints banner if it is successfully loaded and started.
XSROM performs local B-cache initialization and testing on each CPU.
XSROM sizes memory via the system IIC bus.
Each CPU participates in memory initialization and testing.
XSROM loads the SRM system console from system flash ROM.
Console starts on the primary CPU and proceeds to re-size memory.
The primary CPU, running console, signals each secondary (running XSROM) to
start console.
The primary CPU probes each PCI bus and the EISA bus to size the system.
The primary CPU configures and initializes those I/O adapters requiring
initialization.
The system temperature is reported.
The console displays its version banner and console prompt.
For a more detailed description of the test results, see the System Drawer User's
Guide.
System Power-Up and Verification
7-7
