Digital AlphaServer™ 400 Series

User Information

Order Number: EK-PCSVA-UI. A01
Digital Equipment Corporation
Maynard, Massachusetts

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Digital AlphaServer 400 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Digital Equipment Digital AlphaServer 400 Series

Summary of Contents for Digital Equipment Digital AlphaServer 400 Series

  • Page 1: User Information

    Digital AlphaServer™ 400 Series User Information Order Number: EK-PCSVA-UI. A01 Digital Equipment Corporation Maynard, Massachusetts...
  • Page 2 Digital Equipment Corporation. Digital Equipment Corporation assumes no responsibility for any errors that might appear in this document. The software, if any, described in this document is furnished under a license and may be used or copied only in accordance with the terms of such license.
  • Page 3 FCC Information - Class B FCC ID: AO9-PB50 This device complies with Part 15 of the FCC rules. Operation is subject to the following conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules.

  • Page 5: Table Of Contents

    Contents Preface Welcome to the Digital AlphaServer 400 Series System ............xiii Audience ..........................xiii Organization of the Information..................... xiv Conventions........................... xiv Abbreviations ......................... xv Special Notices........................xvii Additional Information Resources ..................xviii 1 Getting Started Introduction ...........................1-1 Before Starting Your System ....................1-2 Posture and Work Habits ....................1-2 Identifying the Correct AC Power Cord ................1-4...
  • Page 6 Contents Security Loop ....................... 1-15 Passwords........................1-15 2 System Overview Introduction........................... 2-1 Motherboard.......................... 2-1 PCI Architecture......................2-1 SCSI Controller ......................2-2 Keyboard..........................2-2 System Front View ........................ 2-4 System Rear View ......................... 2-6 3 Installing System Options Introduction........................... 3-1 Removing the Side Panels ..................... 3-1 System Unit Components ......................
  • Page 7 Contents A Console Commands Introduction .......................... A-1 ARC Console........................A-1 Commands You Need to Know..................A-2 Display Hardware Configuration................A-2 Set Default Environment Variables ................. A-2 Set Default Configuration ..................A-2 Manage Boot Selection Menu ................. A-2 Machine Specific Setup................... A-3 Boot "boot selection identifier"...
  • Page 8 Contents Moving Your System......................B-3 Packing Your System..................... B-3 Installing Your System at a New Location ..............B-3 C Technical Specifications Introduction.......................... C-1 System Specifications......................C-1 External System Connectors ....................C-3 Bidirectional Parallel Port Connector................C-3 Serial Port Connectors ....................C-4 Keyboard and Mouse Connectors...................
  • Page 9 G Equipment Log Introduction .......................... G-1 Equipment Log ........................G-1 Index Figures Digital AlphaServer 400 Series System ..............1-1 Recommendations for Posture and Work Habits............1-3 System Airflow ......................1-8 Voltage Selector Switch .....................1-9 Connecting Cables and Power Cords ................ 1-10 Starting Your System ....................1-11 Keyboard Layout......................2-3...
  • Page 10 Contents System Unit Components ................... 3-3 Motherboard Components ..................3-5 SCSI Address Recommendations ................3-11 System Troubleshooting..................... 4-2 Disk Drive Troubleshooting ..................4-6 Monitor Troubleshooting.................... 4-6 Error Beep Codes....................... 4-7 LED Codes ........................ 4-8 SRM Console Conventions..................A-5 SRM Console Special Characters ................A-6 SRM Boot Command Options...................
  • Page 11 Contents SCSI Addresses......................G-3 System Hardware Configuration................G-4 Installed Software...................... G-4 Additional Component Information................G-4...

  • Page 13: Preface

    AlphaServer 400 Series system. You also can find general system information such as console commands and system care here. Audience If you are operating, configuring, or adding options to the Digital AlphaServer 400 Series system, the information included here is helpful to you. xiii...

  • Page 14: Organization Of The Information

    Preface Organization of the Information This information for users covers the following topics (see the Table of Contents for a detailed listing): • Chapter 1, Getting Started. Installing, starting, restarting, and turning off the system • Chapter 2, System Overview. Motherboard, keyboard, system controls, indicators, ports, and connections •...

  • Page 15: Abbreviations

    Preface Abbreviations This guide uses the following abbreviations: Abbreviation Meaning Advanced RISC Computing (the Windows NT Console). Compact disc. CD-ROM Compact disc read only memory. Central processing unit. Direct memory access. DRAM Dynamic random access memory. DROM Diagnostic read only memory. File allocation table.
  • Page 16 Preface (continued) Light-emitting diode. Media Adapter Unit. An Mb suffix to a numerical value indicates size in megabits (for example, 10 Mb). A megabit equals 1,048,576 bits. A MB suffix to a numerical value indicates size in megabytes (for example, 550 MB). A megabyte equals 1,048,576 bytes. Megahertz.

  • Page 17: Special Notices

    Preface Special Notices This guide uses four kinds of notices to emphasize specific information. ________________________ WARNING __________________________ A WARNING indicates the presence of a hazard that can cause personal injury. ____________________________________________________________ ________________________ CAUTION __________________________ A CAUTION indicates the presence of a hazard that can cause damage to hardware or that might corrupt software.

  • Page 18: Additional Information Resources

    400 Series system: • Digital AlphaServer™ 400 Series Installation Information (order number EK-PCDSA- II) presents a graphical overview of the Digital AlphaServer 400 Series installation. • Digital AlphaStation™ 200/400 Series Technical Information (order number EK- PCDSA-TI). This optional manual contains detailed technical information for value- added resellers (VARs) and independent software vendors.

  • Page 19: Getting Started

    Getting Started Introduction Your Digital AlphaServer 400 Series system is a high-performance computer that uses the latest microprocessor technology. The system can stand alone or function as a server in an office network environment. This chapter describes how to start, install, restart, and turn off your Digital AlphaServer 400 Series system.

  • Page 20: Before Starting Your System

    Getting Started Before Starting Your System Before you start your system, perform the following steps: 1. Read and understand the information supplied with your system. 2. Select a well-ventilated site near a grounded power outlet and away from sources of excessive heat.

  • Page 21: Recommendations For Posture And Work Habits

    Getting Started MLO-011325 Figure 1-2. Recommendations for Posture and Work Habits Table 1-1. Recommendations for Posture and Work Habits Adjust To allow the following conditions Chair 1. Feet are flat on the floor. 2. Legs are vertical and form a right angle to the floor. 3.

  • Page 22: Identifying The Correct Ac Power Cord

    ____________________________________________________________ Identifying the Correct AC Power Cord Your Digital AlphaServer 400 Series system came with the proper AC power cord. Because there are variations from one country to another, and systems may be relocated, please inspect your power cord to ensure it is the correct one for your country or region. If you are not sure that the supplied AC power cord is correct, contact your authorized Digital service representative before you use it.
  • Page 23 UL and CSA Certified cord rated for use at 250 Volts AC with a current rating that is at least 125% of the current rating of the Digital AlphaServer 400 Series system. In Europe, the cordage carries the <HAR> mark.

  • Page 24: System Features

    Getting Started System Features Your Digital AlphaServer 400 Series system includes several features that enhance system reliability, ensure its availability, improve its expansion capabilities, and facilitate hardware management as well as improve system security. Reliability/Availability 64-bit Alpha RISC architecture Provides significantly better performancethan 32-bit architecture does.
  • Page 25 Getting Started (continued) Server Management System diagnostics Allows local and remote diagnosis of system problems. Hardware configuration Allows local and remote system configuration. Unique asset management Unique system identifier in nonvolatile memory provides easy asset management. RAM-based error log Records startup error messages. Firmware upgrade utility Provides verification or firmware versions.

  • Page 26: Installing Your System

    Getting Started Installing Your System The Digital AlphaServer 400 Series system Installation Information you received with your system graphically outlines the steps to follow in installing your system. _______________________ CAUTIONS __________________________ 1. To ensure that your system is properly cooled, make sure that air can freely flow into the front and out of the rear of the system unit.

  • Page 27: Connecting System Parts

    Getting Started Connecting System Parts To connect the components of your Digital AlphaServer 400 Series system, perform the following steps: 1. Confirm that the voltage selector switch matches your local voltage (either 115 Volts or 230 Volts), as Figure 1-4 shows.

  • Page 28: Connecting Cables And Power Cords

    Getting Started 3. Connect the mouse, keyboard, video or terminal cable, and power cords to the system components, as Figure 1-5 shows. ________________________ CAUTION___________________________ The system auxiliary AC outlet is limited to 2 Amps at 115 Volts (1 Amp at 230 Volts).

  • Page 29: Network Connection

    Getting Started Network Connection If you ordered a system with an optional network module, connect your network interface cable to the appropriate port on your network module. Using the console software, you must select which of the two network ports will be used. See Appendix A, Console Commands, for detailed information.

  • Page 30: Preloaded Operating System Software

    If you ordered a system with the Microsoft Windows NT Server operating system, you will see the following display after power-on and initialization: ARC Multiboot Alpha AXP Version 3.5-13 Copyright (c) 1993 Microsoft Corporation Copyright (c) 1993 Digital Equipment Corporation Boot menu: Boot Windows NT Boot an alternate operating system Run a program Supplementary menu...

  • Page 31: Openvms

    Getting Started OpenVMS If you are using the OpenVMS operating system, you will either see a >>> prompt (if auto_action is set to Halt) or the system will proceed to boot OpenVMS (if auto_action is set to Boot) when you power on your system. For more information, refer to your operating system documentation.

  • Page 32: Turning Off Your System

    Getting Started Turning Off Your System Before turning off your system, make sure to save and close all open files. If you turn the system off without saving and closing files, you might lose some or all of your work. Perform the following steps to turn off your system: 1.

  • Page 33: Computer Security

    Chassis Lock To avoid theft of internal components, your Digital AlphaServer 400 Series system comes with a chassis key lock, which is located on the back of your system box. When this lock is in the locked position, no one else can open the system box. Store the key in a safe place.

  • Page 35: System Overview

    System Overview Introduction This chapter describes the Digital AlphaServer 400 Series system hardware components, including the motherboard, PCI (peripheral component interconnect) architecture, keyboard, front panel, and rear panel. Motherboard Your Digital AlphaServer 400 Series system uses high-performance Alpha architecture CPU modules.

  • Page 36: Scsi Controller

    PCI-to-ISA bridge capability that allows you to use commonly available ISA options. SCSI Controller The Digital AlphaServer 400 Series system uses a PCI-based embedded SCSI-2 controller that controls up to seven SCSI peripherals such as hard disk drives, CD-ROM (compact disc read only memory) drives, and tape drives.

  • Page 37: Keyboard Layout

    System Components Figure 2-1. Keyboard Layout Table 2-1. Key Groups and Functions Figure Key, Key Group Function Legend Escape key This key is program specific. Its function is determined by the installed application software. Function key group These keys are program specific. Their functions are determined by the installed application software.

  • Page 38: System Front View

    System Components System Front View Figure 2-2 is a front view of the system showing the location of the controls and indicators. Table 2-2 describes these items. MLO-012666 Figure 2-2. Front Controls and Indicators...

  • Page 39: Front Controls And Indicators

    System Components Table 2-2. Front Controls and Indicators Figure Control or Indicator Function Legend Drive bays Location of three upper 5.25-inch drive bays. Hard drive Location of hidden 3.5-inch drive bay. Floppy drive Location of 3.5-inch diskette drive. Floppy eject button Releases a 3.5-inch diskette from the floppy diskette drive.

  • Page 40: System Rear View

    System Components System Rear View Figure 2-3 shows the rear connectors and lock. Table 2-3 lists the rear connectors and lock and describes their functions. MLO-012667 Figure 2-3. Rear Connectors...

  • Page 41: Rear Connectors

    System Components Table 2-3. Rear Connectors Figure Connector Function Legend Voltage selector switch Allows you to set your system to work with 115 or 230 Volts AC power. Monitor power connector Connects a monitor to AC power. If your monitor consumes more than 2 Amps at 115 Volts (1 Amp at 230 Volts), connect it directly to your wall outlet.

  • Page 43: Installing System Options

    Installing System Options Introduction This chapter explains how to install optional memory, expansion boards, and drives inside your Digital AlphaServer 400 Series system. Removing the Side Panels To remove the side panels, perform the following steps: 1. Turn off your system and all peripheral devices.

  • Page 44: Unlocking And Removing Left Side Panel

    Expanding Your System __________________________NOTE ____________________________ If you are installing or removing drives, you must remove both side panels. Otherwise, remove only the left side panel. ____________________________________________________________ MLO-012678 Figure 3-1. Unlocking and Removing Left Side Panel...

  • Page 45: System Unit Components

    Expanding Your System System Unit Components Figure 3-2 shows the location of the Digital AlphaServer 400 Series system unit components. Table 3-1 lists the system unit components. MLO-012669 Figure 3-2. System Unit Components Table 3-1. System Unit Components Figure Component...

  • Page 46: Motherboard

    Expanding Your System Motherboard Figure 3-3 shows the location of the motherboard components. Table 3-2 lists the motherboard components. MLO-012668 Figure 3-3. Motherboard Components...
  • Page 47 Expanding Your System Table 3-2. Motherboard Components Figure Components Legend ISA expansion slots Combination PCI and ISA expansion slot PCI expansion slots External SCSI connector and bidirectional parallel port Power connector (+3.3 Volts) Serial ports Mouse and keyboard connectors FDC connector Internal SCSI connector Unused Power connector (+5 Volts)

  • Page 48: Installing Additional System Memory

    Expanding Your System Installing Additional System Memory Adding more memory allows your system to run larger, more memory-intensive software more quickly. You can increase your system's memory up to 192 MB. You can add 16-MB, 32-MB, or 64-MB memory options. These memory options are pairs of single in-line memory modules (SIMMs): a 16-MB option consisting of two 8-MB SIMMs, a 32-MB option consisting of two 16-MB SIMMs, or a 64-MB option consisting of two 32-MB SIMMs.

  • Page 49: Adding Memory Modules

    Expanding Your System Adding Memory Modules To add a pair of memory modules (SIMMs), perform the following steps: 1. Turn off your system. Disconnect any external devices and unplug the power cord from the wall outlet. Unplug the power cord and monitor cord from the back of the system unit.

  • Page 50: Installing Expansion Boards

    Expanding Your System Installing Expansion Boards The Digital AlphaServer 400 Series system features two PCI slots, three ISA slots, and one combination PCI and ISA slot. __________________________NOTE ____________________________ The SRM console for DEC OSF/1 and OpenVMS systems assigns available IRQs to PCI devices. IRQs are considered available if they are not assigned to ISA devices in the console's configuration database.

  • Page 51: Installing An Expansion Board

    Expanding Your System MLO-012671 Figure 3-6. Installing an Expansion Board 5. Replace the screw to secure the module. 6. Replace and lock the left side panel. 7. Connect the power cord and monitor cord to the back of the system unit. Connect any external devices and plug the power cord into the wall outlet.

  • Page 52: Adding Mass Storage Devices

    Lower drive bay area. This area has a drive bay assembly that holds a 3.5-inch floppy diskette drive (standard on all Digital AlphaServer 400 Series systems) and one hidden (nonaccessible from the front) 3.5-inch half-height device. This hidden bay is typically used for mounting the system's primary hard disk drive.

  • Page 53: Scsi Termination

    Host adapter (SCSI controller) SCSI Termination The Digital AlphaServer 400 Series system has a built-in SCSI bus that can be connected to both internal (inside the system box) and external SCSI peripherals. Termination is required at both the internal and external ends.

  • Page 54: Installing Devices In The Upper Drive Bay Area

    Expanding Your System Installing Devices in the Upper Drive Bay Area To install a device in the upper drive bay area, perform the following steps: 1. Turn off your system and unlock and remove the side panels, as described earlier in this chapter.

  • Page 55: Removing The Metal Plate

    Expanding Your System MLO-012893 Figure 3-8. Removing the Metal Plate 5. If you are installing a 3.5-inch device, add the 3.5- to 5.25-inch exchange brackets, as Figure 3-9 shows. Fasten the drive with the screws provided. Figure 3-9. Exchange Bracket Mounting 3-13...

  • Page 56: Inserting A Device Into The Upper Drive Bay

    Expanding Your System 6. Insert the new device into the drive bay from the front (Figure 3-10). 7. Secure the device with two screws on each side. Use the three front mounting holes as follows: H for hard drive; T for tape drive; and F for floppy or CD drive. MLO-012673 Figure 3-10.

  • Page 57: Scsi And Fdc Cable Configuration

    Expanding Your System Figure 3-11. SCSI and FDC Cable Configuration 3-15...

  • Page 58: Power Cable Configuration

    Expanding Your System 9. Connect a power cable to the device. Figure 3-12 shows the cables from the power supply. MLO-012679 Figure 3-12. Power Cable Configuration 10. Replace the metal plate that you removed in step 4. 11. Replace and lock the side panels. 12.

  • Page 59: Installing Devices In The Lower Drive Bay Area

    Expanding Your System Installing Devices in the Lower Drive Bay Area The lower drive bay area holds two 3.5-inch devices, a diskette drive, and, typically, a hard disk drive. To upgrade the devices in the lower drive bay area, you must remove the entire drive bay assembly from your system and then remove the devices from the assembly and install the new devices.

  • Page 60: Removing The Lower Drive Bay Assembly

    Expanding Your System MLO-012675 Figure 3-13. Removing the Lower Drive Bay Assembly 3-18...

  • Page 61: Removing The Lower Drive Bay Devices

    Expanding Your System 5. Remove a device by removing the screws on the side and sliding the device out of the lower bay assembly (Figure 3-14). Figure 3-14. Removing the Lower Drive Bay Devices 6. Slide the drive into the drive bay assembly and secure it with screws. ________________________ CAUTION __________________________ Be sure to use the screws that came with the drive.

  • Page 63: Troubleshooting

    Refer to the documentation supplied with additional options if you are experiencing problems with specific options that you have installed. Initial Troubleshooting Follow these general procedures to troubleshoot your Digital AlphaServer 400 Series system initially: 1. Check that the power indicators are on and that the fan is running.

  • Page 64: Equipment Log

    Troubleshooting Equipment Log For your convenience, Appendix G, Equipment Log, includes a form on which you can record all model numbers and serial numbers of your hardware components (system unit, monitor, keyboard, and mouse) and system hardware configuration information (CPU, memory size, drive size, ports, and so on).
  • Page 65 Troubleshooting Table 4-1. System Troubleshooting (continued) Problem Possible Cause Action System does not boot. Operating system Install the appropriate operating software is not installed system. on the hard disk drive. System cannot find the Check the system configuration for boot device. correct device parameters.
  • Page 66 Troubleshooting Table 4-1. System Troubleshooting (continued) Problem Possible Cause Action System does not boot. Environment variables Windows NT: (continued) incorrectly set From the Boot menu, select (continued). Supplementary menu..., then select Setup the system..., then select Set default environment variables. (Refer to Appendix A, Console Commands.) Hard disk drive is not...
  • Page 67 Troubleshooting Table 4-1. System Troubleshooting (continued) Problem Possible Cause Action No response to keyboard Keyboard is password Enter the keyboard password, if commands. protected. supported by your operating system. Keyboard is not connected. Connect the keyboard to the keyboard port. Keyboard is connected to Connect the keyboard to the the mouse port.

  • Page 68: Disk Drive Troubleshooting

    No power at wall outlet. Use another outlet. Power indicator is Contact your service representative defective. or Digital Equipment Corporation. Distorted, rolling, or Monitor incorrectly Adjust accordingly. flickering screen display, adjusted. or wrong/uneven color.

  • Page 69: Error Beep Codes

    Troubleshooting Error Beep Codes Table 4-4 shows error beep codes that you may encounter while using the Digital AlphaServer 400 Series system. For example, if the SROM (serial read only memory) code cannot find any good memory, you hear a 1-3-3 beep code (one beep, a pause, a burst of three beeps, a pause, and another burst of three beeps).

  • Page 70: Interpreting The Led Indicator Values

    Troubleshooting Interpreting the LED Indicator Values Table 4-5 lists the LED indicator values and their meanings. The meanings are valid when the LEDs have stopped sequencing through tests due to an error condition. Table 4-5. LED Codes Indicator Values Meaning Bit 7 Bit 0 Value...

  • Page 71: A Console Commands

    The ARC console supports the use of the Microsoft Windows NT Server operating system. The ARC console uses a menu interface. When a Digital AlphaServer 400 Series system is powered on, initialization is performed. During initialization, the firmware checks the information stored in the nonvolatile memory.

  • Page 72: Commands You Need To Know

    Console Commands Commands You Need to Know Display Hardware Configuration The Display hardware configuration command is located in the Supplementary menu. Use this command to display information about: • Devices that were detected (and are supported) by the ARC console •...

  • Page 73: Machine Specific Setup

    Console Commands • Operating system root directory. • Name (identifier) for this boot selection. • Whether or not the debugger should be initialized at boot time. After you have added a boot selection, use the Check boot selections command to perform verification testing of the selections.

  • Page 74: Install Windows Nt From Cd-Rom

    Console Commands Install Windows NT from CD-ROM The Install Windows NT from CD-ROM command is located in the Supplementary menu. You must put the Microsoft Windows NT Server CD (compact disc) into the CD drive before selecting this command. Switch to OpenVMS or OSF Console The Switch to OpenVMS or OSF console command is located in the Setup menu.

  • Page 75: Srm Console

    Console Commands SRM Console The SRM console supports the OpenVMS and DEC OSF/1 operating systems. The SRM console offers many different commands. For a complete list of SRM commands, type help at the SRM prompt (>>>). This section describes environment variables and the following commands: •...

  • Page 76: Srm Console Special Characters

    Console Commands SRM Console Special Characters Table A-2 lists console special characters and their functions. Table A-2. SRM Console Special Characters Character/Key(s) Function Return Terminates command line input. ß Backspace Deletes the previously typed character. [Ctrl]+[A] Toggles insert/overstrike mode. (Overstrike is the default.) á...

  • Page 77: Boot Command

    Console Commands Boot Command The boot command performs the following functions: • Initializes the processor • Loads a program image from the specified boot device • Transfers control to the loaded image The syntax of the boot command is shown below: boot [-file <filename>] [-flags <longword>[,<longword>]] [-protocols <enet_protocol>] [-halt] [<boot_device>] The boot command options are described in Table A-3.

  • Page 78: Boot Command Examples

    Console Commands Boot Command Examples Table A-4 shows boot command examples and their descriptions. Table A-4. SRM Boot Command Examples Command Description >>>boot Boots the system from the default boot device. Boots the system from Ethernet port ewa0. >>>boot ewa0 >>>boot -file dec2.sys ewa0 Boots the file named dec2.sys from Ethernet port ewa0.

  • Page 79: Set Command

    Console Commands Set Command The set command sets or modifies the value of an environment variable. Environment variables pass configuration information between the console and the operating system. The syntax of the set command is shown below: set <envar> <value> [-default] [-integer] [-string] The set command options are described in Table A-5.

  • Page 80: Show Command

    Console Commands Show Command The show command displays the current value of a specified environment variable. The show command also displays information about the system, according to the arguments entered. The syntax of the show command is shown below: show [{config, device, hwrpb, memory, pal, version, <envar>...}] The show command options are described in Table A-7.

  • Page 81: Show Command Examples

    Console Commands Show Command Examples Table A-8 lists show command examples and their descriptions. Table A-8. SRM Show Command Examples Command Description Lists device information such >>>show device as system designation, drive dka0.0.0.6.0 DKA0 RZ26L 441A model, or Ethernet address. dka400.4.0.6.0 DKA400 RRD43 3213 dva0.0.0.0.1...

  • Page 82: Examine Command

    Console Commands Examine Command The examine command displays the contents of an address you specify. The address can be a memory location, register, device, or file. The syntax of the examine command is shown below: examine [-{b,w,l,q,o,h,d}] [-{physical, virtual, gpr, fpr, ipr}] [-n <count>] [-s <step>] [<device>:]<address>...

  • Page 83: Examine Command Examples

    Console Commands Examine Command Examples Table A-10 shows examine command examples and their descriptions. Table A-10. SRM Examine Command Examples Command Description >>>e r0 Examines R0 using a symbolic address. gpr: 0 (R0) 0000000000000002 Examines R0 using address space. >>>e -g 0 gpr: 0 (R0) 0000000000000002...

  • Page 84: Deposit Command

    Console Commands Deposit Command The deposit command writes data to an address that you specify. The address can be a memory location, register, device, or file. The syntax of the deposit command is shown below: deposit [-{b,w,l,q,o,h}] [-{physical,virtual,gpr,fpr,ipr}] [-n <count>] [-s <step>] [<device>:]<address> <data> The deposit command options are described in Table A-11.

  • Page 85: Deposit Command Examples

    Console Commands Table A-11. SRM Deposit Command Options (continued) Command Option Description <address> An address that specifies the offset within a device into which data is deposited. The address can also be any legal symbolic address. Valid symbolic addresses are: •...

  • Page 86: Environment Variables

    Console Commands Environment Variables Table A-13 shows selected environment variables and their descriptions (for a complete list, type show * at the SRM prompt). Table A-13. SRM Environment Variables Variable Description auto_action Sets/shows the console action following an error, halt, or power-up. The action can be halt, boot, or restart.

  • Page 87: Isa Configuration Utility

    AlphaServer 400 Series system running either the DEC OSF/1 or OpenVMS operating systems. The Digital AlphaServer 400 Series system has five IRQ levels available for ISA and PCI expansion (5, 9, 10, 14, and 15). Prior to adding an ISA device, you must use ISACFG to assign an IRQ to the device.
  • Page 88 Console Commands Table A-14. SRM ISACFG Command Options (continued) Command Option Description -enadev <#> Allows you to specify whether an entry is enabled or disabled. Disabled devices are not used in resource allocation calculations. The possible values are: 0 - No (disabled) 1 - Yes (enabled) -etyp <#>...

  • Page 89: Adding Isa Options To Openvms And Dec Osf/1 Systems

    Console Commands Adding ISA Options to OpenVMS and DEC OSF/1 Systems When you add a supported ISA option to an AlphaServer 400 Series system running the OpenVMS or DEC OSF/1 operating system, perform the procedure in Table A-15. Table A-15. Adding Options to OpenVMS or DEC OSF/1 Systems Step Action Result or Next Step...

  • Page 90: Isacfg Command Examples

    Console Commands ISACFG Command Examples This section shows examples of ISACFG commands you use to enter the DE205, sound card, and FAX/MODEM options into the configuration database. Examples to display, modify, and remove table entries are included as well. In some cases, scripts are available to issue the proper ISACFG command.

  • Page 91: B System Care

    System Care Introduction This appendix describes how to: • Clean your system, including the outside enclosure, monitor screen, mouse, and keyboard • Move your system ________________________ WARNING __________________________ Make sure you turn off the system and disconnect any external devices before cleaning any part of your system.

  • Page 92: Cleaning Your Mouse

    System Care ________________________ WARNING __________________________ If you use a prepackaged screen cleaner, make sure that it is nonflammable. Never spray the cleaner directly on the screen. Instead, apply the cleaner to a clean cloth, and then wipe the screen. ____________________________________________________________ Cleaning Your Mouse If your mouse does not move smoothly or if the pointer jumps across the screen when you are using the mouse, the ball inside the mouse might need cleaning.

  • Page 93: Moving Your System

    System Care Moving Your System Perform the following steps before shipping or moving the system: 1. Back up all files stored on the hard disk drive. 2. Turn off the external peripherals, the system, and the monitor. 3. Disconnect the power cord from the wall outlet and from the back of the system unit. 4.

  • Page 95: C Technical Specifications Introduction

    Expansion slot current limitations • System current requirements • Motherboard jumpers System Specifications Tables C-1 through C-4 list the Digital AlphaServer 400 Series system processor features, dimensions, environmental, and acoustics specifications. Table C-1. System Specifications Attributes Specification PCI clock 33 MHz...

  • Page 96: Acoustics-Declared Values Per Iso 9296 And Iso 7779

    Technical Specifications Table C-2. System Dimensions Dimension Specification Width 177.8 mm (7.0 in) Length 431.8 mm (17.0 in) Height 431.8 mm (17.0 in) Weight 12+ kg (28+ lb) Table C-3. System Environmental Specifications Attributes Specification Operating temperature 10°C to 40°C (50°F to 104°F) −20°C to 65°C (−4°F to 149°F) Storage temperature Operating humidity...

  • Page 97: External System Connectors

    Technical Specifications External System Connectors This section lists the pin assignments for your system's external connectors: • Bidirectional connector, 25-pin D-submini female • Serial connectors, 9-pin D-submini male • Keyboard and mouse connectors, 6-pin mini-DIN • SCSI port, high-density, shielded Bidirectional Parallel Port Connector The bidirectional connector provides an interface to a printer or other parallel devices.

  • Page 98: Serial Port Connectors

    Technical Specifications Serial Port Connectors The serial port connectors consist of two 9-pin D-submini connectors. Table C-6 lists their pin assignments. The baud rates supported by the system's serial ports are 300; 1200; 2400; 4800; 9600; 19,200; and 38,400. Table C-6. 9-Pin Serial Port Pinouts DB9 Pin Signal Function...

  • Page 99: Scsi Port Connector

    Technical Specifications SCSI Port Connector The external SCSI connector is a 50-pin high-density connector. Table C-8 lists the pin assignments. Table C-8. SCSI Port Pinouts Signal Signal –DB (0) –DB (1) –DB (2) –DB (3) –DB (4) –DB (5) –DB (6) –DB (7) –DB (P) reserved...

  • Page 100: Expansion Slots

    Technical Specifications Expansion Slots The motherboard contains two PCI, three ISA, and one combination PCI/ISA expansion slots. The maximum available +5 Volts DC current allowable to any expansion slot depends on the following parameters: • Power supply capacity • +5 Volts DC requirements of the motherboard •...

  • Page 101: Motherboard Jumper Locations

    Technical Specifications ________________________ CAUTION __________________________ Do not touch any electronic component unless you are safely grounded. Wear a grounded wrist strap or touch an exposed metal part of the system unit chassis. A static discharge from your fingers can permanently damage electronic components.

  • Page 102: Cpu Module Jumpers

    Technical Specifications Table C-10. Motherboard Jumper Settings Jumper Setting Function Description 1 to 2 CMOS clear CMOS clear 2 only (D) Normal 1 to 2 Password clear Password clear (not used on the AlphaServer 400 2 only (D) Normal system) 1 to 2 Color Display type (not used on...

  • Page 103: Cpu Module Jumper Settings

    Technical Specifications Table C-11. CPU Module Jumper Settings Jumper Setting Function Description 1 to 2 SROM mini-console J3 is used to control whether the SROM code 2 to 3 (D) Pass control to DROM goes to the mini console (for manufacturing) or loads the DROM code.

  • Page 105: D Device Mapping Introduction

    Device Mapping Introduction This appendix lists system device mapping information, including: • I/O address map • Interrupt assignments • DMA channel assignments I/O Address Map Table D-1 presents information on the I/O address map. Table D-1. I/O Address Map ISA I/O Devices Addresses 0000-02F7...

  • Page 106: Interrupt Map

    Device Mapping Interrupt Map The IRQ assignments for the Digital AlphaServer 400 Series are shown in Table D-2. This information is useful when adding or reconfiguring options on your system. Avoid conflicts when assigning IRQs by associating one IRQ to one source. PCI interrupt levels are set either by the operating system (as in the Windows NT operating system) or by the SRM console (as in the OpenVMS and DEC OSF/1 operating systems).

  • Page 107: Dma Channel Assignments

    Device Mapping DMA Channel Assignments The DMA channel assignments for ISA options are shown in Table D-3. This information is useful when adding ISA options to your system. Avoid DMA channel conflicts by not assigning multiple devices to the same channel. Table D-3.

  • Page 109: E Updating System Firmware Introduction

    ____________________________________________________________ System Firmware The Digital AlphaServer 400 Series system contains four flashROMs, two with ARC (advanced RISC computing) console firmware (for the Windows NT operating system) and two with SRM (system reference manual) console firmware (for the DEC OSF/1 and OpenVMS operating systems).

  • Page 110: Using The Flash Update Utility From The Srm Console

    Upgrading System Firmware Using the Flash Update Utility From the SRM Console To update the firmware from the SRM console, do the following: 1. Insert the Firmware Update CD-ROM (compact disc read only memory) into the CD drive. 2. Type the show device command to determine the device ID of the CD drive. >>>show device dka0.0.0.6.0 DKA0...
  • Page 111 Upgrading System Firmware apu-version 959328854 *** Firmware Update Utility V2.9 *** *** System Type: Alpha Workstation 200/400 *** Update Verify List Show Dump Verbose Nverbose Debug Ndebug Apu-> 4. To update the firmware, type update. The following information will be displayed as the firmware is being updated.

  • Page 112: Using The Flash Update Utility From The Arc Console

    Upgrading System Firmware Using the Flash Update Utility From the ARC Console To update the firmware from the ARC console, do the following: 1. Insert the Firmware Update CD-ROM (compact disc read only memory) into the CD drive. 2. From the ARC Boot Menu, select Supplementary menu... 3.

  • Page 113: F Starting An Operating System Installation Introduction

    Starting an Operating System Installation Introduction This information provides what you need to begin an operating system installation. Once you have started an installation, follow the on-screen instructions and refer to the appropriate operating system documentation. Using the table below, first locate the operating system you want to install and refer to the appropriate table number.

  • Page 114: Starting A Windows Nt Server Installation

    Starting an Operating System Installation Starting a Windows NT Server Installation Digital partitions and formats disk 0 on the first SCSI controller in non-RAID Windows NT Server systems. The partitions are set up as follows: • Partition 1 (typically, the "C" drive) is the size of the disk less 6 MB and formatted FAT.

  • Page 115: Setting Up Partitions For A Windows Nt Server Installation

    Starting an Operating System Installation If you are installing the operating system on a disk that has not been partitioned and formatted, follow the procedure in Table F-2. Table F-2. Setting Up Partitions for a Windows NT Server Installation Step Action Result If the ARC (advanced RISC...
  • Page 116 Starting an Operating System Installation Table F-2. Setting Up Partitions for a Windows NT Server Installation (continued) Step Action Result Select the desired target device. A prompt for partition size appears. The system partition should be 6 MB. Enter the desired partition size of Partition successfully created.

  • Page 117: Starting A Dec Osf/1 Installation

    Starting an Operating System Installation Starting a DEC OSF/1 Installation To start a DEC OSF/1 installation, follow the steps in Table F-3. Table F-3. Starting a DEC OSF/1 Installation Step Action Result If the SRM console is running, go to Selecting Switch to OSF will cause the system step 3.

  • Page 118: Starting An Openvms Installation

    Starting an Operating System Installation Starting an OpenVMS Installation To start an OpenVMS installation, follow the steps in Table F-4. Table F-4. Starting an OpenVMS Installation Step Action Result If the SRM console is running, go to Selecting Switch to OpenVMS causes the step 3.

  • Page 119: G Equipment Log

    Equipment Log Introduction With the Equipment Log, you can gather information that you may need if problems occur with your system and you need to call Digital for assistance. Use the Equipment Log to record information about your system hardware and software components.

  • Page 120: Hardware Components

    Equipment Log Table G-1. Hardware Components Component Vendor/ Model Serial Date Type/Size Number Number Installed System unit Digital 400 Series AlphaServer System unit key number Monitor Keyboard Mouse Installed diskette drive Additional storage device 1 Additional storage device 2 Additional storage device 3 Additional storage device 4...
  • Page 121 Equipment Log Table G-2. ISA Equipment Configuration Device Handle Slot IOBASE Membase DMAmode and chan Memlen Keyboard Mouse MOUSE Serial Line 1 COM1 Serial Line 2 COM2 Parallel port LPT1 FLOPPY Motherboard ISA Expansion Slots Table G-3. SCSI Addresses Address Device SCSI controller...

  • Page 122: Digital Alphaserver 400 Series System

    Equipment Log Table G-4. Hardware Configuration Component Digital AlphaServer 400 Series System Specifics CPU speed and model Firmware version Memory size Video module Table G-5. Installed Software Operating System or Version License Number Date Application Software Number Installed Table G-6. Additional Components...
  • Page 123 Index Abbreviations used, xv Baud rates Add-on procedure serial port, C-4 expansion boards, 3-8 ISA options on DEC OSF/1 or OpenVMS, 3-9 lower bay devices, 3-17 Cable orientation, 3-14 mass storage, 3-10 Cleaning memory, 3-7 computer, B-1 SIMMs, 3-7 monitor screen, B-1 upper bay devices, 3-12 Components Adding memory, 3-6...
  • Page 124 Index Console switching from ARC to SRM, 1-13 Features switching from SRM to ARC, 1-13 keyboard, 2-2 Console commands, A-1 PCI, 2-2 Console update utility, E-1 SCSI, 2-2 Controls and indicators, 2-5 Firmware Conventions used, xiv update utility, E-1 Cooling, 1-8 updating, E-1 Flash update utility, E-2 Floppy eject button, 2-5...
  • Page 125 Index shutdown, 1-14 Keyboard, 2-2 angle, 2-2 Packing cleaning, B-2 computer, B-3 connector, C-4 Padlock ring, 1-15 key groups and functions, 2-3 Parallel port connector, 2-7 Passwords, 1-15 PCI, 2-1 LEDs Pinouts diagnostic, 4-1, 4-7 bidirectional parallel port, C-3 values, 4-8 parallel, C-3 Lifting components, 1-2 SCSI port, C-5...
  • Page 126 Index controller, 2-2 special characters, A-6 port, C-5 Startup termination, 3-11 connecting components, 1-9 external, 3-11 power on sequence, 1-11 internal, 3-11 voltage selection, 1-9 software controlled, 3-11 System Security, 1-15 Serial port, C-4 troubleshooting, 4-2 baud rates, C-4 controls and indicators, 2-4 Shutdown, 1-14 front view, 2-4 Side panels, 3-1...
  • Page 127 Index partitioning the disk, F-3 shutdown, 1-14 Windows NT, 1-12 starting an install, F-2 arcinst, F-3 creating partitions, F-3 Index-5...

Table of Contents
