High End Systems DML-1200 User Manual page 43

Global Functions
DMX
Value
93
Film Burn/Unburn create a burn pattern on the image
94 Film Noise creates an "aged" film effect
95 Particle System 1 converts image to a particle pattern
96 Particle System 2 adds adjustments to Effect 95
97 Particle System 3 adds adjustments to Effect 95 + Effect 96
98
Prism
Gaussian Halo creates blur from clear center toward the edges of an
99
100 Scene Change Detect transparency effect
101
Yxy Luminance Scaling adjusts brightness without effecting color
102
Prerotation Translation places object in 3-D space
103
Digital Mspeed.
128
Mask Color applies color to mask parameter selection
129
Edge Fade Color applies color to Edge Fade parameter selection
Mask Color and Edge Fade Color applies the same color to both the
130
selected Mask and Image Edge Fade parameters
131
Background Color selects background color
132 Background Color Cycle sequences the background color
133 Edge Fade Profiles defines edge fading patterns
Collage Generator creates multi-fixture panorama displays, (see
134
Collage Generator™ Effect
Curve Correction, Vertical Convex Cylinder corrects shape projecting
135
on curved surface
Curve Correction, Vertical Concave Cylinder corrects shape
136
projecting on curved surface
Curve Correction, Vertical Inside Corner corrects shape projecting on
137
curved surface
Curve Correction, Vertical Outside Corner corrects shape projecting
138
on curved surface
Curve Correction, Outside Sphere corrects shape projecting on a
139
sphere's outside surface
Curve Correction, Inside Sphere corrects shape projecting on a
140
sphere's inside surface
Enhanced Collage Generator provides higher resolution for collage
141
arrays larger than 4 x 4.
Spherical Mapping, Outside maps output to a portion of a sphere's
142
outside surface.
Spherical Mapping, Inside maps output to a portion of a sphere's
143
inside surface.
144 Mattes apply provided mattes over image
Collage Generator Wrap adds right and left edge blending for 360
145
degree panoramas
Segmented Collage Generator accepts user defined portion of
146
content for each cell in the grid
Segmented Collage Generator Wrap adds right and left edge
147
blending to the user defined cell content for 360° panoramas
Curved Surface, Horizontal Convex Cylinder
148
corrects shape projecting on curved surface
Curved Surface, Horizontal Concave Cylinder corrects shape
149
projecting on curved surface
DML-1200 w/Axon Embedded Graphic Engine 24/12/2010 _____________________________________________________________________________ 40
Effect Mode Name/Description
on page 43).
Adjustments
Modifier 1 Modifier 2
Burn/Unburn Rate Film Blackening
Push to Sepia
Noise Rate
add Jitter
Emitter Type Trail Length
Number of Particles Particle Size
Initial Particle Particle
Velocity Rotation
Number of Facets Refraction Index
Sample Number of
Distance Filter Passes
Scale RGB RGB to Alpha
Scale Luminance Scale X
Translate X Translate Y
Rotation MSpeed Scaling MSpeed
Red Green
Red Green
Red Green
Red Green
Red Speed Green Speed
Selects Mode Adjusts Profile
Selects array cell
Selects Array Type
for display
Adjusts Correction Sets Vertical Center
Adjusts Correction Sets Vertical Center
Adjusts Correction Sets Vertical Center
Adjusts Correction Sets Vertical Center
Adjusts Correction Sets Vertical Center
Adjusts Correction Sets Vertical Center
Selects array
Selects Array Type
cell to display
Sets Longitude Sets Latitude
Angle Angle
Sets Longitude Sets Latitude
Angle Angle
Matte Effect Matte Pattern
Selects array
Selects Array Type
cell to display
Selects array
Selects Array Type
cell to display
Selects array
Selects Array Type
cell to display
Sets Horizontal
Adjusts Correction
Center
Sets Horizontal
Adjusts Correction
Center
Modifier 3
Burn
Pattern
Noise Level
Particle Acceleration
Emitter Size
Particle
Lifetime
Rotation
Gaussian
Curve Shape
Scale color with
alpha applied
Scale
Translate Z
Position MSpeed
Blue
Blue
Blue
Blue
Blue Speed
Selects Source
Adjusts Edge
blending
Not Used
Not Used
Sets Horizontal
Center
Sets Horizontal
Center
Sets Horizontal
Center
Sets Horizontal
Center
Adjusts Edge
blending
Sets Latitude
Center
Sets Latitude
Texture Source
Adjusts Edge
blending
Adjusts Edge
blending
Adjusts Edge
blending
Not Used
Not Used
