6. Loosen the two screws in the left inner and outer collars using a Phillips screwdriver.
7. Slide the inner and outer collars onto the left cover.
8. Insert the tabs of the collars into the slots of the cover.
9. Tighten the two screws using a Phillips screwdriver.
10. Repeat steps 1 through 9 for the right side.
Install foot pads
Have one person lift the unit while a second person places a foot pad under each of the two back feet.
Level unit
This procedure will level the unit by evenly adjusting the weight on the rear feet. Leveling the unit will
eliminate rocking during use.
Note: References to left and right are from the users perspective during use.
1. Verify foot plates are completely stopped.
Cybex 771A/771AT, 772A/772AT Arc Trainer Part Number 5771-4 K
1
2
3
4
1
Page 23 of 95
Description
Screws
Inner collar
Outer collar
Cover
Description
Foot pads
Qty
2
1
1
1
Qty.
2
