Setup - CYBEX 771A Owner's Manual

2. Remove the nut at the end of the coax cable.
3. Insert the coax cable into the D-shaped hole in the mounting plate on the front of the unit.
4. Thread the nut removed in step 2 onto the coax cable.
5. Install the coax cable to the mounting plate on the front of the unit using a 14 mm open end wrench.
6. Plug the Ethernet or HDMI cable into the coupler on the front of the unit.
Visually inspect unit
1. Remove any packing material from unit.
2. Examine the unit to ensure that the assembly is correct and complete.

Setup

Use the following instructions to setup the unit.
1. Plug the optional power cord or E3 View Monitor power cord (E3 View Monitor units only) into a
power outlet from a grounded circuit.
Coil up the remainder of the power cord and place it out of the way. The control panel will light up
and be in the Dormant Mode.
2. Hold the handrails to steady self while stepping into the foot plates.
3. Begin striding.
Initial setup
Perform this procedure during the installation of the unit. Once complete, refer to Setup Options below.
1. Tap the Access Toolbox icon to display the Access to Toolbox login screen.
Cybex 771A/771AT, 772A/772AT Arc Trainer Part Number 5771-4 K
CYBEX LOGO
LANGUAGE ICON
1
2
Press and hold Cybex logo for 6 seconds to access
Screen Lock and Toolbox.
Press and hold language logo for 6 seconds to ac-
cess Screen Lock and Toolbox.
Page 43 of 95
Description
Coax cable
Nut
Qty.
1
1
