CYBEX 771A Owner's Manual page 25

4. Adjust the weight of the rear feet using a 1/2" open-end wrench.
• If the left rear foot lifts up easier, Adjust the right leveling foot nut down.
• If the right rear foot lifts up easier, Adjust the left leveling foot nut down.
Left leveling foot shown
5. Test the unit again for uneven weight on the rear feet. Adjust leveling foot nuts until each rear foot
lifts with even force.
6. Secure both jam nuts using a 9/16" open-end wrench. Unit is leveled.
Install optional Audio Visual cables
The optional audio visual cables can include combinations of Coax, Ethernet, or HDMI cables.Mounting
plate has three holes for all configuration options:
• Coax Only (EPEM Tuner or MYE CableSAT w/coax)
• Coax and Ethernet (Cybex GO or BV CAB w/coax)
• Ethernet Only (BV CAB TV on a stand)
• HDMI Only (MYE CableSAT w/HDMI)
• Ethernet and HDMI (BV CAB)
Cybex 771A/771AT, 772A/772AT Arc Trainer Part Number 5771-4 K
1
2
3
Turn clockwise to adjust level-
4
Page 25 of 95
Description
Frame post
Leveling foot nut
Leveling foot
ing foot down
Qty.
1
1
1
1
