The E3 View Monitor is supplied with a power cord,
Use Cybex supplied AC power kit only. Consult an electrician with any questions.
Verify the unit is connected to an outlet having the same configuration as the plug.
Verify connection is a grounded circuit. Do not use a ground-plug adapter to adapt the 3-prong power
cord to a non-grounded electrical outlet.
Verify power supply is compliant with local building codes.
Assembly Procedure 771A/772A
Two people will be required for this procedure.
Read and understand all instructions thoroughly before assembling this unit. Check all items
carefully. If there is damage, see the Customer Service section of this manual for proper procedure
to return, replace, or reorder parts.
The words "left" and "right" denote the user's orientation.
Verify you have received the correct package
1. Read box label to verify the model number and voltage (optional) match what was ordered.
2. Verify paint color matches what was ordered.
Verify parts list shown below
Item Quantity
1 1
2 1
3 2
4 1
5 1
6 1
7 1
8 1
9 1
10 1
11 1
12 1
13 1
14 1
15 1
16 1
Cybex 771A/771AT, 772A/772AT Arc Trainer Part Number 5771-4 K
Part Number
Varies
Varies
12090-322
-
-
770A-316
770A-317
770A-318
770A-322
770A-323
770A-324
770A-319
770A-321
770A-320
-
5771-X
Base assembly
Console assembly
Foot pad
Handle, Right
Handle, Left
Base, Accessory tray
Cover, Top, Accessory tray
Cover, Bottom, Accessory tray
Cover, Rear, Top, Right
Cover, Rear, Outer, Right
Cover, Rear, Inner, Right
Cover, Rear, Top, Left
Cover, Rear, Inner, Left
Cover, Rear, Outer, Left
Hardware pack
Owner's Manual
Page 14 of 95
Description
