Connectors
2
7.2 I C connector CN2
Pin number
1
2
3
4
7.3

Analog input-output connector CN3

Pin number
1
32/80
2
Figure 9. I C connector CN2 (Front view)
Table 18. I
Description
I2C1_SDA (PB9)
NC
I2C1_SCL (PB8)
RESET (PC10)

Figure 10. Analog input-output connector CN3 (Top view)

Table 19. Analog input-output connector CN3

Description
analog input-output (PF10)
DocID029088 Rev 3
2
C connector CN2
Pin number
5
6
7
8
Pin
number
2
UM2036
Description
+3V3
NC
GND
NC
Description
GND
