Daughterboard extension connectors CN5 and CN6

Two 60-pin male headers CN5 and CN6 can be used to connect a daughterboard or the
standard wrapping board to the STM32F779I-EVAL evaluation board. All GPIOs are
dispatched on memory connectors (CN10 and CN11), and on connectors CN5 and CN6.
The space between these two connectors is defined as a standard which allows developing
common daughterboards for several ST evaluation boards. The standard width between
CN5 pin 1 and CN6 pin 1 is 2700mils (68.58mm).
Each pin on CN5 and CN6 can be used by a daughterboard after disconnecting it from the
corresponding function block on the STM32F779I-EVAL evaluation board. For more details
refer to Table 21
Pin Description
1 GND
3 PH0
5 RESET#
7 PF6
9 PF10
11 PC0
13 PA2
15 PA0
17 PF8
19 GND
21 PA4
23 PC2
25 PC4
27 PC3
29 PB2
31 PJ3
33 PB10
35 PB14
37 PH6
39 GND
41 PB12
43 PB13
45 PJ9
47 PG7
34/80
and Table 22.

Table 21. Daughterboard extension connector CN5

Alternative function
-
OSC_IN
-
QSPI_BK1_IO3
Potentiometer
ULPI_STP
SAI2_SCKB/MII_MDIO/MC_EnIndex
SAI2_SDB/ MII_CRS/MC_ENA
QSPI_BK1_IO0
-
PAR_HSYNC
MII_TXD2/MC_CurrentB
MII_RXD0/
MC_BUSVOLTAGE
MII_TX_CLK/ MC_CurrentC
QSPI_CLK
LCD_R4/LED3
ULPI_D3/LCD_G4
USB_FS2_DM
MII_RXD2/MC_DissipativeBrake
-
ULPI_D5/ USB_FS2_ID
ULPI_D6/ USB_FS2_VBUS
-
NAND_INT
DocID029088 Rev 3
How to disconnect with function block on
STM32F779I-EVAL board
-
Remove X1,C23, Close SB40
-
Remove R241
Remove R30
Remove R123
Open SB37, SB35
Open SB43, SB45, SB47
Remove R242
-
Disconnect CN4
Open SB49, remove R245
Open SB51, SB54
Open SB52, SB56
-
Open SB59
Remove R100, open SB63
Disconnect CN14
Open SB53, SB55
-
Open SB65, remove R107
Remove R263, R113
-
Open SB19
UM2036
