UM2036
Pin number
1
3
5
7
9
11
13
15
17
19
7.11

USB OTG1 FS Micro-AB connector CN13

Pin number
1
2
3

Table 28. ETM trace debugging connector CN12

Description
+3.3V
GND
GND
KEY
GND
GND
GND
GND
GND
GND

Figure 16. USB OTG1 FS Micro-AB connector CN13 (Front view)

Table 29. USB OTG1 FS Micro-AB connector CN13

Description
VBUS (PA9)
D- (PA11)
D+ (PA12)
DocID029088 Rev 3
Pin
number
2
4
6
8
10
12
14 TraceD0/PE3 or SWO/PB3
16 TraceD1/PE4 or nTRST/PB4
18
20
Pin number
4
5
-
Connectors
Description
TMS/PA13
TCK/PA14
TDO/PB3
TDI/PA15
RESET#
TraceCLK/PE2
TraceD2/PE5
TraceD3/PE6
Description
ID (PA10)
GND
-
43/80
