Figure 35. Stm32F779I-Eval Can And Quad-Spi - ST STM32F779I-EVAL User Manual

CAN
PA12
CAN1_TX
PA11
CAN1_RX
Quad SPI Flash
QSPI_BK1_IO3
QSPI_BK1_NCS
QSPI_BK1_IO1

Figure 35. STM32F779I-EVAL CAN and Quad-SPI

R183
R189
+3V3
C179
10K 0
Default setting: 1<->2
JP19
100nF
U23
1 8
D RS
2 7
GND CANH
3 6
VCC CANL
4 5
R Vref
SN65HVD230
U3
PF6 R241 33 1 16
HOLD#/DQ3 CLK
2 15
+3V3 VCC DQ0
C105
3 14
NC NC
100nF
+3V3 4 13
NC NC
5 12
NC NC
R230
10K 6 11
NC NC
PB6 7 10
CS# Vss
PF9 R231 33 8 9
DQ1 W#/Vpp/DQ2
MICRON
MT25QL512ABA8ESF-0SIT
N25Q512A13GSF40E MICRON
+3V3
CN26
DB9-male CAN connector
Default setting: Open
1
6
JP18 2
7
3
8
R185 4
120 9
D15 5
ESDCAN24-2BLY R184 R186
Optional
[N/A] 0
+3V3
PB2
QSPI_CLK
R242 33 PF8
QSPI_BK1_IO0
R232 33 PF7
QSPI_BK1_IO2
Title: CAN & QSPI
Project: STM32F779I-EVAL
Size: A4 Reference:
Date: 2016/4/26
MB1219 Revision: B.1
Sheet: 11 of 17
