UM2036
Pin number
1
2
3
7.8

Ethernet RJ45 connector CN9

Pin number
1
3
5
7
7.9

Memory connector CN10 and CN11

Two 40-pins male headers CN10 and CN11 are used to connect with memory
daughterboard. GPIOs (which work as FMC memory signals) that are not present on CN5
and CN6, are available on these two connectors.
The space between these two connectors is defined as a standard which allows to develop
common daughterboard. The standard width between CN10 pin 1 and CN11 pin 1 is
1914 mils (48.62 mm). For more details on signal assignment refer to
Table 28.

Table 24. USB OTG HS Micro-AB connector CN8

Description
VBUS
D-
D+

Figure 14. Ethernet RJ45 connector CN9 (Front view)

Table 25. RJ45 connector CN9

Description
TxData+
RxData+
Shield
Shield
DocID029088 Rev 3
Pin number
4
5
-
Pin
number
2
4
6
8
Connectors
Description
ID
GND
-
Description
TxData-
Shield
RxData-
Shield
Table 27 and
39/80
