STM32F779I-EVAL I/O assignment
Pin No. Pin Name
P6 PF14
P7 PJ2
P8 PF11
P9 PE9
P10 PE11
P11 PE14
P12 PB10
P13 PH6
P14 PH8
P15 PH10
R1 VDDA
R2 PA3
R3 PA7
R4 PB1
R5 PB0
R6 PJ0
R7 PJ1
R8 PE7
R9 PE10
R10 PE12
R11 PE15
R12 PE13
R13 PB11
R14 PB14
R15 PB15
56/80
Table 38. STM32F779I-EVAL I/O assignment (continued)
STM32F779I-EVAL
standard
A8
LCD_R3/DSI_TE
SDNRAS
D6
D8
D11
ULPI_D3
MII_RXD2
D16
D18
-
ULPI_D0
MII_RX_DV
ULPI_D2
ULPI_D1
LCD_R1/LED1
LCD_R2/LED2
D4
D7
D9
D12
D10
ULPI_D4
USB_FS2_DM
USB_FS2_DP
