UM2036
Pin number
11
13
15
17
19
7.14

microSD connectors CN17 and CN30

Pin
number
1
2
3
4
5
Table 31. JTAG/SWD debugging connector CN16 (continued)
Description
RTCK
PB3
RESET#
DBGRQ
DBGACK

Figure 19. microSD connector (Top view)

Table 32. microSD card1 connector CN17

Description
SDMMC_D2 (PC10)
SDMMC_D3 (PC11)
SDMMC_CMD (PD2)
+3.3V
SDMMC_CLK (PC12)
DocID029088 Rev 3
Pin
number
12
14
16
18
20
Pin
Description
number
6
7 SDMMC_D0 (PC8)
8 SDMMC_D1 (PC9)
9
MicroSDcard_detect1 (MFX
10
Connectors
Description
GND
GND
GND
GND
GND
Vss/GND
GND
GPIO15)
45/80
