Figure 33. STM32F779I-EVAL USB OTG FS

+5V
MFX_GPIO7 R130 0
OTG_FS1_PowerSwitchOn
From MFX
R129
10K
PA9
VBUS_FS1
PA11
USB_FS1_DM
PA12
USB_FS1_DP
PA10 R115 0
USB_FS1_ID
+3V3
R127
620
R131 LD8
47K
U11 Red
2 3 R132 0
GND FAULT
5 1
IN OUT
4 D2_N
EN
D2_P
C47
STMPS2151STR
4.7uF
D5
ESDA6V1BC6
R106
47K
MFX_GPIO6
OTG_FS1_OverCurrent
To MFX
CN13
1
VBUS
2
DM
3
DP
4
ID
5
GND
6
Shield
7
Shield
8
Shield
9
Shield
10
EXP
475900001
+3V3
R116
330
LD7
Green
T7
1
9013
R103
22K
Title: USB_OTG_FS
Project: STM32F779I-EVAL
Size: A4 Reference: MB1219 Revision: B.1
Date: 2016/4/26 Sheet: 9 of 17
