Figure 32. Stm32F779I-Eval Usb Otg Hs - ST STM32F779I-EVAL User Manual

PB13
VBUS_FS2
PB14
USB_FS2_DM
PB15
USB_FS2_DP
PB12
USB_FS2_ID
OTG_FS2_PowerSwitchOn
From MFX
PH4 R121 0
ULPI_NXT
PI11 R122 0
ULPI_DIR
PC0 R123 0
ULPI_STP
PA5 R124 33
ULPI_CK
ULPI_D[0..7] PB5 ULPI_D7 R117
ULPI_D[0..7]
PB13 ULPI_D6 R113
PB12 ULPI_D5 R107
PB11 ULPI_D4 R104
PB10 ULPI_D3 R100
PB1 ULPI_D2 R98
PB0 ULPI_D1 R93
PA3 ULPI_D0 R86
R85
+3V3
1M
X5 Soldered if reset is
controlled by hardware
R126
4K7
24MHz
R125
C38 C37 T1
1
RESET#
33pF 33pF 9012
1K
R108
4K7

Figure 32. STM32F779I-EVAL USB OTG HS

D7
ESDA6V1BC6
MFX_GPIO9 SB23 Open
R92
10K
+5V
SB24
U8 Closed
11 3
NXT CPEN
12 10
DIR EXTVBUS
13 32 R96
STP RBIAS
14 12K[1%]
CLKOUT
4
VBUS
8
DM
0 17 7
D7 DP
0 18 5
D6 ID
0 19
D5
0 20 31
D4 REG_EN
0 21 16
D3 VDD3.3
0 22 6 C145 C143
D2 VDD3.3
0 23 25 100nF 100nF
D1 VDD3.3
0 24 30
D0 VDD3.3
15
VDD1.8
27 26
XO VDD1.8
28 29
XI VDDA1.8
C40
2 C141
GND
1 100nF 4.7uF
GND
9 33
RESET GNDPAD
USB3300-EZK
CN14
1
VBUS
D1_N 2
DM
D1_P 3
DP
4
ID
5
GND
6
Shield
7
Shield
8
Shield
9
Shield
10
EXP
475900001
R119 0 MFX_GPIO8
SB22 +3V3
R120
Open
3K3
LD6
R288
2 1
620
U7
2 3 Red
GND FAULT
5 1
IN OUT
4 C35
EN
4.7uF
SB21
STMPS2151STR
Closed
L2 VBUS_HS
R101 820
D0_N EXC-3BP121H[BEAD]
D0_P
+3V3
C146 C142
100nF 100nF D4 D3
USBULC6-2F3 ESDA14V2-2BF3
C34 C43 C33 C42
C41
C46 100nF 100nF 100nF 100nF
100nF 4.7uF
Title:
USB_OTG_HS
Project: STM32F779I-EVAL
Size: A4
Date: 2016/4/26
+3V3
R133
330
LD9
Green
R136
1 T2
9013
47K
R137 +3V3
22K
R94
OTG_FS2_OverCurrent
330
To MFX
LD5
Green
R82
T6
1
9013
47K
R78
22K
CN8
1
VBUS
2
DM
3
DP
4
ID
5
GND
6
Shield
7
Shield
8
Shield
9
Shield
10
EXP
L1 475900001
EXC-3BP121H[BEAD]
Reference: MB1219 Revision: B.1
Sheet: 8 of 17
