Connectors
Table 22. Daughterboard extension connector CN6 (continued)
Pin Description
56 PD7
58 PC6
60 +5 V
7.6

RS-232 connector CN7

Pin number
1
2
3
4
5
7.7

USB OTG2 HS Micro-AB connector CN8

38/80
Alternative Function
SD2_CMD
MC_UH/PAR_D0/I2S3_CK
-

Figure 12. RS-232 connector CN7 (Front view)

Table 23. RS-232 connector CN7

Description
NC
RS232_RX (PA10)
RS232_TX (PA9)
NC
GND

Figure 13. USB OTG HS Micro-AB connector CN8 (Front view)

DocID029088 Rev 3
How to disconnect with function block on
STM32F779I-EVAL board
Disconnect SD2
Open SB18, disconnect CN4, keep JP9 on open
Pin
number
6 Bootloader_BOOT
7
8 Bootloader_RESET
9
-
UM2036
-
Description
NC
NC
-
