Hardware layout and configuration
172.72mm
6.1

Embedded ST-LINK/V2-1

The ST-LINK/V2-1 programming and debugging tool is integrated on the STM32F779I-
EVAL evaluation board. Compared to ST-LINK/V2 the changes are listed below.
The new features supported on the ST-LINK/V2-1 are:
• USB software re-enumeration
•
Virtual COM port interface on USB
• Mass storage interface on USB
•
USB power management request for more than 100 mA power on USB
This feature is no more supported on the ST-LINK/V2-1:
•
SWIM interface
•
Minimum supported application voltage limited to 3 V
12/80

Figure 4. Mechanical dimensions

31.34mm
2
28
14
15
2
60
59
32 25
24
8
17
9 16
39 40
GND OUT
36
VIN 25
24
37 37
5
6
13
48
48
12
20.18mm
DocID029088 Rev 3
156.85mm
68.58mm
48.62mm
2
34
15
2
59
39 40
49
25
50
24 2
13
12
9
2
87mm
39
48 37
36
12
25
60
13 24
19 20
37.7mm
20.18mm
UM2036
16.76mm
55.32mm
79.45mm
