Chapter 5

UCC/EAN-128

Note: Code 128 must be Enabled for UCC/EAN-128 to function.
Definition: A subset of Code 128, with extended features. (See the Uniform Code
Council, Inc. at
Usage: Used as a standard for shipping symbols.
UCC/EAN-128 Status
Serial Cmd: <K474,,,,UCC/EAN-128
arator status,application record separator character,application record
brackets,application record padding>
Note: Code 128 serial command fields for K474 precede UCC/EAN-128.
Default: Disabled
Options: 0 = Disabled
If set to Enabled, symbols can be read with or without a function 1 character in the
first position.
If set to Required, the symbol must have a function 1 in the first position and con-
form to EAN format in order to decode the bar code symbol.
Output Data Format (UCC/EAN-128)
Definition: Offers an option between Standard UCC/EAN-128 and Application
Record format.
Usage: Application Record is useful in applications in which the software can
utilize application record formatting to help automate the processing of
its UCC/EAN-128 data.
Serial Cmd: <K474,,,,UCC/EAN-128
arator status,application record separator character,application record
brackets,application record padding>
Default: Standard
Options: 0 = Standard
In Standard UCC/EAN-128 application identifiers and data fields are sent, but none
of the formatting (separators, parentheses, padding) will be included.
Application Record is a variation of UCC/EAN-128 that allows the user to define sep-
arators between data fields, enclose application identifiers in parentheses, and enable
padding (zeros) for variable length fields.
Note: If an illegal Application Record format is detected, the scanner will process it
as a noread and output a noread message (if enabled).
MS-3 Laser Scanner User's Manual
www.uc-council.org.)
status,output format,application record sep-
1 = Enabled 2 = Required
status,output format,application record sep-
1 = Application Record
Symbology
5-21
