Functional characteristics

Menus and sub-menus on the machine control

5.8 Menus and sub-menus on the machine control
5.8.1

Direct menus (direct access to parameters)

Functions, parameters and their values can be accessed directly, e.g. can be selected by pressing a
button once.
5.8.2

Expert menu (TIG)

The expert menu includes functions and parameters which are either not set on the machine control, or
which do not require regular setting.
Display
48
Setting/selection
Expert menu
Slope time tS1 (main current to secondary current)
Setting: 0.00 s to 20.0 s (factory setting 0.01 s)
Slope time tS2 (secondary current to main current)
Setting: 0.00 s to 20.0 s (factory setting 0.01 s)
Wire return
• Increase value = more wire return
• Reduce value = less wire return
Parameter can also be set after connecting a TIG cold wire feed unit. Setting: 0 to 255
(factory setting 50).
activArc parameter
Parameter can also be set after activating TIG activArc welding.
Display shown = factory setting.
Figure 5-16
Item No.: 099-000155-EWM01
