Operating instructions

Welding machines for
TIG and MMA welding
These operating instructions must be read before commissioning.
Failure to do so may be dangerous.
Machine may only be operated by personnel familiar with the appropriate safety
regulations.
The machines bear the conformity mark and thus comply with the
• EC Low Voltage Guideline (73/23/EEC)
• EC EMV Directive (89/336/EEC)
In compliance with IEC 60974, EN 60974, VDE 0544 the machines can be used in
environments with an increased electrical hazard.
© 2008
Subject to alteration!
EWM HIGHTEC WELDING GmbH
Dr. Günter - Henle - Straße 8; D-56271 Mündersbach
Phone: +49 (0)2680.181-0; Fax: +49 (0)2680.181-244
www.ewm.de
Internet:
; E-mail:
Art. Nr.: 099-002004-EWM01
info@ewm.de
GB
Stand: 15.02.2008
