5.3.2

Optimising the ignition characteristics for pure tungsten electrodes

This parameter can be used to improve the ignition characteristics of "pure tungsten electrodes", for
example. The parameter is a %-value (factory-set to 20) and is changed across all JOBs.
Control element
5.3.3

TIG automatic cut-out

If the arc does not ignite after starting or if the arc is interrupted when the torch is
moved away, an automatic cut-out occurs after 3 sec. The HF, gas and open circuit
voltage (power unit) are switched off.
Item No.: 099-000155-EWM01
Action Result
Select Ignition Characteristics parameter
1 x
The signal lights for the selected electrode
diameter and ignition current AMP% flash for
approx. 5 seconds. The parameter value can
be optimised on the rotary transducer during
this time.
Set parameter value
Increase parameter value:
more ignition power
Reduce parameter value:
less ignition power
Functional characteristics
NOTE
TIG welding
Display
