Specifications - AXIOMTEK SBC84820 Series User Manual

SBC84820 Pentium
1.1

Specifications

®
CPU: Intel Pentium
System Chipset: Intel
Bus Clock: 400/533 MHz
BIOS:
Phoenix-Award BIOS, Y2K compliant
4Mbit Flash, DMI, Plug and Play
SmartView for multiple LCD type selection, display
mode option and application extension features
RPL/PXE Ethernet Boot ROM
"Load Optimized Default" to backup customized
Setting in the BIOS flash chip to prevent from CMOS
battery fail
System Memory:
One 200-pin DDR2 SO-DIMM Socket.
Maximum up to 1GB
L2 Cache: Integrated in CPU
Onboard IDE:
2 channels up to 3 devices (1 parallel ATA-100 and 1
serial ATA-150)
PATA-100 as PIO Mode 0-4, DMA Mode 0-2 and Ultra
DMA/33/66/100
Onboard Serial ATA:
Independent DMA operation.
Data transfer rate up to 150 Mbyte/s
Compact Flash Socket:
Support Compact Flash type-II Socket jumper
selectable as Master or Slave and DMA mode
supported
Power is 3.3V (Default) or 5V (Option).
Introduction
®
M All-in-One Capa Board User's Manual
®
M and Celeron
®
915GM + ICH6M
®
M
3
