SBC84820 Pentium M All-in-One Capa Board User's Manual
Soft-Off by PWR-BTTN
This option only works with systems using an ATX power supply. It also
allows the user to define which type of soft power OFF sequence the
system will follow. The default value is "Instant-Off" .
This option follows the conventional manner systems
perform when power is turned OFF. Instant-Off is a
Instant-Off
soft power OFF sequence requiring only the switching
of the power supply button to OFF
Upon turning OFF system from the power switch, this
option will delay the complete system power OFF
Delay 4
sequence by approximately 4 seconds. Within this
Sec. delay period, system will temporarily enter into
Suspend Mode enabling you to restart the system at
once.
Power On by Ring
This option allows the system to resume or wake up upon detecting any
ring signals coming from an installed modem. The default value is
"Enabled" .
IRQ 8 Break Suspend
You can turn on or off monitoring of IRQ8 (the Real Time Clock) so it
does not awaken the system from Suspend mode. The default value is
"Disabled" .
Reload Global Timer Events
When Enabled , an event occurring on each device listed below restarts
the global time for Standby mode.
56
Award BIOS Utility
