SBC84820 Pentium
2.4

Connectors

The connectors allow the CPU card to connect with other parts
of the system. Some problems encountered by your system
may be a result from loose or improper connections. Ensure
that all connectors are in place and firmly attached. The
following table lists the function of each connector on the
SBC84820 Series. Their corresponding pin assignments are
described in Chapter 3.
Connectors
Digital I/O Connector
Front Panel Bezel Connector
Parallel IDE Connector
Printer Port Connector
USB Port2 & Port3 Connector
LVDS Connector
Power Connector
LVDS Voltage Connector
Serial Port2 Connector
LAN Connector
Audio Connector
USB Port0 & Port1 Connector
6-Pin Mini Dim Keyboard/Mouse Connector
TV-OUT Connector
Serial Port1 Connector
VGA Connector
SATA Connector
FDD Connector
Compact Flash Connector
Extension SLOT
FAN Connector
DDRⅡSO-DIMM
Jumpers and Connectors
®
M All-in-One Capa Board User's Manual
Label
CN1
CN2
CN3
CN4
CN5
CN6
CN7
CN8
CN9
CN10
CN11
CN12
CN13
CN14
CN15
CN16
CN17
CN18
CN19
J1
FAN1
SODIMM1
13
