SBC84820 Pentium M All-in-One Capa Board User's Manual
Primary Master/Primary Slave/Secondary
Master/Secondary Slave
The categories identify the types of one channel that have been installed
in the computer. There are 45 predefined types and 2 users definable
types are for Enhanced IDE BIOS. Type 1 to Type 45 is predefined. Type
User is user-definable.
Press <PgUp>/<+> or <PgDn>/< − > to select a numbered hard disk type
or type the number and press <Enter>. Note that the specifications of
your drive must match with the drive table. The hard disk will not work
properly if you enter improper information within this category. If your
hard disk drive type does not match or is not listed, you can use Type
User to define your own drive type manually.
If you select Type User, related information is asked to be entered to the
following items. Enter the information directly from the keyboard and
press <Enter>. This information should be provided in the documentation
from your hard disk vendor or the system manufacturer.
If the controller of HDD interface is ESDI, select " Type 1 " .
If the controller of HDD interface is SCSI, select " None " .
If the controller of HDD interface is HARD DISK, select " None " .
number of cylinders
CYLS.
number of heads
HEADS
PRECOMP write precom
If there is no hard disk drive installed, select NONE and press <Enter>.
Drive A type/Drive B type
The category identifies the types of floppy disk drive A or drive B installed
in the computer.
38
landing zone
LANDZONE
number of sectors
SECTORS
MODE HDD access mode
Award BIOS Utility
